7-24
■ Setup data setting
0 to 16 : t/c
48 to 52 : linear (DC current, DC voltage)
64 to 71 : RTD
96 to 103: RTD
128 to 134: linear (DC current, DC voltage)
[Description:]
For details see range numbers listed in ÒSection 2-3
Input Type and Range NumberÓ (page 2-8)
0 C 01 1 PV1 range number
0: ¡C Celsius
1: ¡F Fahrenheit
[Description:]
When setting C01 is set to linear, Т-----У is displayed and
setting cannot be performed.
0 C 02 2 PV1 temperature unit
0 to 2
A setting of 0 means no decimal point and a setting of 1
and 2 indicates the number of decimal digits.
[Description:]
When setting C01 is set to linear, Т-----У is displayed and
setting cannot be performed.
The setting range varies with the C01 and C02 setting.
¥ A setting between 0 and 2 can be made when C01 is
set to: 5, 15, 65 to 69, 97 to 101 and C02 is set to 0.
C01 settings: 66, 68, 69, 98, 100, 101 and C02 is set
to 1.
¥ A setting of 0 and 1 can be made when C01 is set to:
0 to 4, 6 to 14, 16, 64, 70, 71, 96, 102, 103and C02 is
set to 0.
C01 settings: 0 to 5, 7, 8, 10, 12 to 14, 16, 64, 65, 67,
70, 71, 96, 97, 99, 102, 103and C02 is set to 1.
¥ Only a setting of 0 is possible when C01 is set to: 6, 9,
11 and C02 is set to 1
When the C01 setting is set to t/c or RTD, this setting is
reflected in PVU (PV1) units.
1 C 03 3 PV1 decimal point position
0 to 4
A setting of 0 means no decimal point and a setting
between 1 and 4 indicates the number of decimal digits.
[Description:]
C01 settings for t/c and RTD display Т-----У and setting
cannot be performed.
When the C01 setting is set to linear, this setting is
reflected in PVU (PV1) units.
1 C 04 4 PV1 linear decimal point
position
Ð19999 to +20000 PVU (PV1)
[Description:]
When the C01 settingis set to t/c and RTD display Т-----У
and setting cannot be performed.
Reversing the lower limit and upper limit makes it
possible to reverse analog inputs and specified values.
0 PVU C 05 5 PV1 linear range lower limit
10000PVU C 06 6 PV1 linear range upper limit
0: Provided (compensated internally)
1: Not provided (compensated externally)
[Description:]
When the C01 setting is set to t/c and RTD display Т-----У
and setting cannot be performed.
0 C 07 7 PV1 cold junction
compensation
0: Not provided
1: Provided
[Description:]
When the C01 setting is set to t/c and RTD display Т-----У
and setting cannot be performed.
0 C 08 8 PV1 square root extraction
0.2 to 10.0% (ratio depends on input range)
[Description:]
When the C01 setting is set to t/c and RTD display Т-----У
and setting cannot be performed.
0.2 C 09 9 PV1 square root extraction
dropout
Ð1.0 to +1.0¡C
[Description:]
When the C01 setting is set to t/c and RTD display Т-----У
and setting cannot be performed.
Use 0.0 for normal settings.
0.0 C 10 10 PV1 cold junction bias
Item code Item No.
User
settings
Settings and descriptions
Factory default
settings
Chapter 7. PARAMETER SETUP
