DCP552 Parameter Work Sheet
No. Item code
Item
Factory default User
Settings and descriptions
settings
settings
61
C 61
Programming system
0
0 : RAMP-X and RAMP-T (θ) combined
1 : RAMP-X and RAMP-E (∆SP) combined
62
C 62
Program time unit
0
0 : Hours, min (SPU/hour for RAMP-T)
1 : Min, sec (SPU/min for RAMP-T)
2 : 0.1 sec (SPU/sec for RAMP-T)
63
C 63
Time display (display panel 1
0
0 : Remaining segment time
and 2)
1 : total operation time (after READY → RUN start)
65
C 65
SP decimal point position (CH1) 1
0 to 4
66
C 66
SP limit lower limit
PV1 range
–19999 to +20000 SPU
lower limit
67
C 67
SP limit upper limit
PV1 range
–19999 to +20000 SPU
upper limit
68
C 68
SP decimal point position (CH2) 1 or 3
0 to 4 on a model without CP compensation.
0 to 3 on a model with CP compensation.
69
C 69
SP limit lower limit (CH2)
PV2 range
-19999 to +20000 SPU (CH2) on a model without CP
lower limit
compensation.
0 to 2000 SPU(CH2) on a model with CP compensation.
70
C 70
SP limit upper limit (CH2)
PV2 range
upper limit
71
C 71
External switch input RSW5
0
0 : NOP (does not function)
1 : RAMP-E
2 : FAST
72
C 72
External switch input RSW6
0
3 : G.SOAK is cleared using OR
4 : G.SOAK is cleared using AND
5 : MANUAL/AUTO
73
C 73
External switch input RSW7
0
6 : AT start/terminate
7 : NOP (does not function)
8 : Auto load
74
C 74
External switch input RSW8
0
9 : NOP (does not function)
10 : NOP (does not function)
11 : O
2
sensor check
75
C 75
External switch input RSW9 to 14
0
0 : BCD4 bit + BCD2 bit
(program selection)
1 : Binary 6 bits
76
C 76
Communication address
0
0 to 127
77
C 77
Transmission rate
0
0 : 9600bps
1 : 4800bps
2 : 2400bps
3 : 1200bps
78
C 78
Transmission code
0
0 : 8 bits, even parity, 1 stop bit
1 : 8 bits, no parity, 2 stop bits
79
C 79
Communication protocol
0
0 : CPL
1 : ST221 (no PV trend)
2 : ST221 (PV trend)
80
C 80
Communication method
0
0 : RS-485
1 : RS-232C
81
C 81
ROM ID
—
< Description >
82
C 82
ROM ITEM
—
Can only be referenced for mechanical service use.
83
C 83
ROM revision
—
84
C 84
Data version
—
85
C 85
CPU board ID
—
86
C 86
I/O board ID
—
90
C 90
PID type
1
0 : Improved
1 : Compatible with Mark I
91
C 91
PV1 burnout
0
0 : Provided
1 : Not provided
92
C 92
PV2 burnout
0
0 : Provided
1 : Not provided
93
C 93
Time proportional output system 0
0 : Does not go on a second time in time proportional cycle.
(CH1)
1 : Goes on a second time in time proportional cycle.
94
C 94
Time proportional output
0
0 : Does not go on a second time in time proportional cycle
system (CH2)
1 : Goes on a second time in time proportional cycle
