7-8
Item code
Item
No.
User
settings
Settings and descriptions
Factory default
settings
PA 93
Auto-tuning (CH2)
93
0: AT not performed
1: standard AT performed on currently used PID group in
mode other than READY mode.
2: AT writing overshoot-proof PID values to currently used
PID groups in mode other than READY mode performed.
3: Standard AT performed on PID groups A1 to A7 in READY mode.
4: AT writing overshoot-proof PID values to PID groups
A1 to A7 in READY mode continuously performed.
[Description:]
Т-----У is displayed for models with CP compensation and setting cannot be performed.
0
PA 94
Auto-tuning MV lower limit
(CH2)
94
-5.0 to upper limit %
[Description:]
Т-----У is displayed for models with CP compensation and setting cannot be performed.
Valid when setup data
C22
setting is set to 1, 3 or 5.
0.0
PA 95
Auto-tuning MV upper limit
(CH2)
95
Lower limit to +105%
[Description:]
Т-----У is displayed for models with CP compensation and setting cannot be performed.
Valid when setup data
C22
setting is set to 1, 3 or 5.
100.0
PA 96
PID computation initialize
(CH2)
96
0: No initialization during advance processing and PID group change
1: Initializes during advance processing but not during PID group change
2: No initialization during advance processing but
initializes during PID group change
3: Initializes both during advance processing and PID group change
0
PA 97
CP computation
compensation
97
0: No compensation
1: compensates
[Description:]
Т-----У is displayed for models without CP compensation and setting cannot be performed.
0
PA 98
CP value (PV) display lower
limit value
98
0 to upper limit SPU (CH2)
[Description:]
Т-----У is displayed for models without CP compensation and setting cannot be performed.
0.000
PA 99
CP value (PV) display upper
limit value
99
lower limit to 4000 SPU (CH2)
[Description:]
Т-----У is displayed for models without CP compensation and setting cannot be performed.
4.000
PA 100
Gas constant
100
10.0 to 50.0 %
[Description:]
Т-----У is displayed for models without CP compensation and setting cannot be performed.
23.5
PA 101
CP computation compensation No. 1 compensation point
101
No. 1 compensation point
: 0 SPU (CH2) (tied)
No. 2 to 9compensation point : 0 to +2000 SPU (CH2)
NO. 10 compensation point
: 2000 SPU (CH2) (tied)
NO. 1 to 10 compensation amount
: -1000 to +1000 SPU (CH2)
[Description:]
бТ-----У is displayed for models without CP compensation
and setting cannot be performed.
бТ-----У is displayed when
PA97
is set to 0 and setting
cannot be performed.
0.000
PA 102
CP computation compensation No. 1 compensation amount
102
0.000
PA 103
CP computation compensation No. 2 compensation point
103
0.200
PA 104
CP computation compensation No. 2 compensation amount
104
0.000
PA 105
CP computation compensation No. 3 compensation point
105
0.400
PA 106
CP computation compensation No. 3 compensation amount
106
0.000
PA 107
CP computation compensation No. 4 compensation point
107
0.600
PA 108
CP computation compensation No. 4 compensation amount
108
0.000
PA 109
CP computation compensation No. 5 compensation point
109
PA 110
CP computation compensation No. 5 compensation amount
110
PA 111
CP computation compensation No. 6 compensation point
111
PA 112
CP computation compensation No. 6 compensation amount
112
PA 113
CP computation compensation No. 7 compensation point
113
PA 114
CP computation compensation No. 7 compensation amount
114
PA 115
CP computation compensation No. 8 compensation point
115
PA 116
CP computation compensation No. 8 compensation amount
116
PA 117
CP computation compensation No. 9compensation point
117
PA 118
CP computation compensation No. 9compensation amount
118
PA 119
CP computation compensation No. 10 compensation point
119
PA 120
CP computation compensation No. 10 compensation amount
120
0.800
0.000
1.000
0.000
1.200
0.000
1.400
0.000
1.600
0.000
2.000
0.000
Chapter 7. PARAMETER SETUP
