7-5
■
Variable parameter setting
0: AT not performed
1: Standard AT performed on currently used PID group
in mode other than READY mode.
2: AT writing overshoot-proof PID values to currently
used PID groups in mode other than READY mode
performed.
3: Standard AT performed on PID groups A1 to A7 in
READY mode.
4: AT writing overshoot-proof PID values to PID groups
A1 to A7 in READY mode continuously performed.
0: Keylock disabled
1: Display of setup data settings disabled
2: Display of all settings disabled
3: Display of all settings disabled.Operation keys disabled
[Description:]
PA01
can be displayed and changed regardless of
PA01
and
PA02
settings.
Item code
Item
No.
User
settings
Settings and descriptions
Factory default
settings
PA 01
Keylock
1
0
PA 02
Memory protect
2
0
PA 03
Display channel setting
3
0: 2 items are displayed for the selected CH
1: Simultaneous 2CH display of the same item
0
PA 04
Synchronous 2 channel
operation
4
0: asynchronous
1: synchronous
0
PA 05
Program auto load
5
1: ON
2: OFF
0
PA 06
Unused
6
[Description:]
Ò-----Óis displayed and setting cannot be performed.
Ð
PA 07
Unused
7
Ð
PA 08
Auto-tuning (CH1)
8
0
PA 09
Auto-tuning MV lower limit
(CH1)
9
Ð5.0 to upper limit %
[Description:]
Valid when setup data
C21
setting is set to 1, 3, 5.
0.0
PA 10
Auto-tuning MV upper limit
(CH1)
10
Lower limit to +105%
[Description:]
Valid when setup data
C21
setting is set to 1, 3, 5.
100.0
PA 11
SP bias (CH1)
11
Ð10000 to +10000 SPU (CH1)
0 SPU
PA 12
PV digital filter (CH1)
12
0.0 to 120.0sec
0.0
PA 13
PV bias (CH1)
13
Ð1000 to +1000 PVU (PV1)
0 PVU
PA 14
Manipulated variable
deviation limit (CH1)
14
0.1 to 110.0% OUT/0.1sec
110.0
PA 15
Time proportional output
cycle (CH1)
15
1 to 240sec
10
PA 16
On-off control differential
(CH1)
16
0 to +1000 SPU (CH1)
50 SPU
PA 17
PID computation initialize
manipulated variable (CH1)
17
Ð5.0 to +105.0%
0.0
PA 18
Unused
18
[Description:]
Ò-----Óis displayed and setting cannot be performed.
-----
PA 19
Unused
19
-----
PA 20
Unused
20
-----
PA 21
SP bias (CH2)
21
Ð10000 to +10000 SPU (CH2)
0 SPU
PA 22
PV digital filter (CH2)
22
0.0 to 120.0sec
0.0
PA 23
PV bias (CH2)
23
Ð1000 to +1000 PVU (PV2)
0 PVU
0: Disabled
1: Program settings are protected
2: Setup, variable parameters and event configurations
are protected.
3: Setup, variable parameters and event configurations
are protected.
4: Setup, variable parameters and event configurations
are protected.
5: Program settings and all parameter settings are
protected.
[Description:]
PA02
can be displayed and changed regardless of
PA01
and
PA02
settings.
Chapter 7. PARAMETER SETUP
