11-3
Item Specifications
Mode
Control section
Output section
Program run mode READY
RUN
HOLD
FAST
END
READY FAST
Proportional band (P) PID control 0.0 to 1000.0% (0.0: On-off control)
Integral time (I) 0 to 3600s (0: PD control)
Derivative time (D) 0 to 1200s (0: PI control)
Manipulated variable
limit
Low-limit : Ð5.0 to high-limit%
High-limit : Low-limit to +105.0%
Manual reset 0.0 to 100.0%
Auxiliary output
Auto tuning Automatic setting of PID value by limit cycle method
Manipulated variable change 0.1 to 110.0%/0.1s
On-off control differential 0 to 1000U
Scaling Possible
Type SP1, PV1, deviation 1, MV1, SP2, PV2, deviation 2,
O 2 sensor mV value
PID groups selection Segment specified, automatic zone selectable during
program run
No. of PID groups 16 groups for program operation (9 segment specific
and 7 automatic zone selecting)
Fixed command control
mode
READY : Preparation state (control stop)
RUN : Run state
AUTO : Automatic run state
MANUAL: Manual run state (output is operatable to console)
AUTO : Automatic run state
MANUAL: Manual run state (Enables manual output from system console.)
Normal reverse operation selection Selection is settable
Current output (5G)
CH1,CH2
Auxiliary output CH1, CH2
Output current
Allowable load resistor
Output accuracy
Output resolution
Max. output current
Min. output current
Output update cycle
Open time terminal voltage
: Preparation state (control stop, select of program number is possible.)
: Advancing run state
: Hold run state
: Fast feed run state
: End point run state
: Preparation and the fast feed state
: 4 to 20mA DC
: Lower than 600½ (under operating conditions)
: Lower than ± 0.1% FS (under standard conditions)
: 1/10000
: 21.6mA DC
: 2.4mA DC
: 0.1s
: Lower than 25V
Voltage output (6D)
CH1,CH2
Allowable load resistor
Load current adjustment
Open time terminal voltage
Off time leakage current
Output response time
Output resolution
Time proportional cycle
: Lower than 600½ (under the action conditions)
: 2 to 22mA variable
: Lower than 25V
: Lower than 100 µ A
: Lower than 0.5ms on on-off 600½ load
Lower than 0.5ms off-on 600½ load
: 1/1000
: 1 to 240s variable
Chapter 11. SPECIFICATIONS
