15
DCP552 Parameter Work Sheet
No. Item code Item Factory default User Settings and descriptions
settings settings
1 C 01 PV1 range number 0 0 to 16 : Thermocouple
48 to 52 : Linear (DC current and DC voltage)
64 to 71 : Resistance temperature detector
96 to 103 : Resistance temperature detector
128 to 134 : Linear (DC current and DC voltage)
2 C 02 PV1 temperature unit 0 0 : Celsius (°C)
1 : Fahrenheit (°F)
3 C 03 PV1 decimal point position 1 0 to 2
4 C 04 PV1 linear decimal point position 1 0 to 4
5 C 05 PV1 linear range lower limit 0 PVU –19999 to +20000 PVU(PV1)
6 C 06 PV1 linear range upper limit 10000 PVU –19999 to +20000 PVU(PV1)
7 C 07 PV1 cold junction compensation 0 0 : Provided (Compensated inside the instrument)
1 : Not provided (Compensated outside the instrument)
8 C 08 PV1 root extraction 0 0 : Not provided
1 : Provided
9 C 09 PV1 root extraction dropout 0.2 0.2 to 10.0% (Ratio to input range)
10 C 10 PV1 cold junction bias 0.0 –1.0 to + 1.0°C
11 C 11 PV2 range number 0 0 to 16 : Thermocouple
48 to 52 : Linear (DC current and DC voltage)
64 to 71 : Resistance temperature detector
96 to 103 : Resistance temperature detector
128 to 134 : Linear (DC current and DC voltage)
135
: O
2
sensor (CP)
12 C 12 PV2 temperature unit 0 0 : Celsius (°C)
1 : Fahrenheit (°F)
13 C 13 PV2 decimal point position 1 0 to 2
14 C 14 PV2 linear decimal point position 1 0 to 4
15 C 15 PV2 linear range lower limit 0 PVU –19999 to +20000 PVU(PV2)
16 C 16 PV2 linear range upper limit 10000 PVU –19999 to +20000 PVU(PV2)
17 C 17 PV2 cold junction compensation 0 0 : Provided (Compensated inside the instrument)
1 : Not provided (Compensated outside the instrument)
18 C 18 PV2 root extraction 0 0 : Not provided
1 : Provided
19 C 19 PV2 root extraction dropout 0.2 0.2 to 10.0% (Ratio to input range)
20 C 20 PV2 cold junction bias 0.0 –1.0 to + 1.0°C
21 C 21 Control output system (CH1) 1 1 : 5G output (Current proportional control output)
2 : 6D output (Voltage time proportional control output) system A
3 : 6D output (Voltage time proportional control output) system B
4 : 8D output (open collector time proportional control output) system A
5 : 8D output (open collector time proportional control output) system B
22 C 22 Control output system (CH2) 1
23 C 23 Control action (CH1) 0 0 : PID — A reverse operation
1 : PID — A normal operation
2 : PID — B reverse operation
3 : PID — B normal operation
24 C 24 Control action (CH2) 0
30 C 30 PV equalizer 0 0 : None
1 : PV1 only
2 : PV2 only
3 : Both PV1 and PV2
31 C 31 End of operation (CH1) 0 0 : READY mode
1 : END mode
32 C 32 Manipulated variable in READY 0.0 –5.0 to +105.0%
mode (CH1)
33 C 33 Manipulated variable setting 0 0 : No
in PV overrange (CH1) 1 : Yes
■ Setup data setting
