7-27
0 to 3600sec
When set to 0, operation continues regardless of outage
time.
[Description:]
The HOLD mode is invoked when the outage is longer
than set time.
The measurement of a power outage may vary by about
10 seconds.
0: No
1: Yes
0 C 39 39 Manipulated variable setting
in PV overrange (CH2)
-5 to +105% 0.0 C 40 40 Manipulated variable in PV
overrange (CH2)
0: smooth
1: preset
0 C 41 41 Manual change mode (CH2)
-5 to +105% 0.0 C 42 42 Preset manual value (CH2)
0: oxygen pressure (PO
2
) computation
1: CP computation for NKG sensor
2: CP computation for Marathon monitors and Cambridge
sensors
3: CP computation for Corning sensors
4: CP computation for AACC sensors
5: CP computation for Barber-Coleman sensors
6: CP computation for Furnace Control sensors
[Description:]
Т------У is displayed for a model without CP compensation
and setting cannot be performed.
1 C 44 44 CP computation type (varies
with sensor manufacturer)
0 C 43 43 Length of outage permitting
continuous operation
[Description:]
Т-----У is displayed and setting cannot be performed.
---- C 51 51 Unused
---- C 52 52
0: SP1
1: PV1
2: Deviation1 (DEV1)
3: Manipulated variable 1 (MV1)
4: SP2
5: PV2
6: Deviation 2 (DEV2)
7: Manipulated variable 2 (MV2)
8: O
2
sensor mV input value
[Description:]
Т-----У is displayed and setting cannot be performed on
model without auxiliary output or with one auxiliary
output.
0 C 48 48 Auxiliary output type 2
---- C 53 53 Unused
Unused
---- C 54 54 Unused
----
---- C 55 55
C 56 56
Unused
Unused
0: SP1
1: PV1
2: Deviation1 (DEV1)
3: Manipulated variable 1 (MV1)
4: SP2
5: PV2
6: Deviation 2 (DEV2)
7: Manipulated variable 2 (MV2)
8: O
2
sensor mV input value
[Description:]
Т-----У is displayed and setting cannot be performed on
model without auxiliary output.
0 C 45 45 Auxiliary output type 1
Ð19999 to +20000 SPU ( C45 not equal to 3, 7)
Ð1999.9 to +2000.0 SPU ( C45 set to 3, 7)
[Description:]
Т-----У is displayed and setting cannot be performed on
model without auxiliary output.
0 SPU C 46 46 Auxiliary output 1 lower limit
(4mA)
10000SPU C 47 47 Auxiliary output 1 upper limit
(20mA)
Ð19999 to +20000 SPU ( C48 not equal to 3, 7)
Ð1999.9 to +2000.0% ( C48 set to 3, 7)
[Description:]
Т-----У is displayed and setting cannot be performed on
model without auxiliary output or with one auxiliary
output.
0 SPU C 49 49 Auxiliary output 2 lower limit
(4mA)
10000SPU C 50 50 Auxiliary output 2 upper limit
(20mA)
Item code Item No.
User
settings
Settings and descriptions
Factory default
settings
Chapter 7. PARAMETER SETUP
