Honeywell DCP552 Mark II - Manual (Page 188)

11-6
Item Specifications
General
specifications
Insulated resistor Higher than 50M½ under DC 500V megger during power supply terminal (39) or
(40) and FG terminal ((52) or (53))
Withstand voltage 1500V AC 50/60Hz for 1 min across power terminal and frame ground terminal
Note: Primary and secondary sides are capacitive coupled inside the ,+2## .
Thus disconnect the ground wire from the secondary side terminal (for
example, when using a grounded thermocouple) before performing a
withstand voltage test. Failure to do so may result in equipment damage.
Standard conditions Ambient temperature 23 ± 2¡C
Ambient humidity 60 ± 5% RH
Rated power supply voltage 105V AC ± 1%
Power supply frequency 50 ± 1Hz or 60 ± 1Hz
Vibration resistance 0m/s 2
Shock resistance 0m/s 2
Mounting angle Reference plane (vertical) ± 3¡
Operating conditions Ambient temperature
range
0 to 50¡C (the ambient temperature at the bottom of the
case when hermetically sealed inside case)
Transportation and
storage conditions
Ambient temperature
range
Ð20 to 70¡C
Terminal screw M3.5 self-up screw
Terminal screw tighten torque 0.78 to 0.98Nám
Mask and case material Mask : Multiron Case : Multiron
Mounting Panel flush-mount
Weight Approx 1.5kg
Mask and case color Musk : Dark gray (Munsell sign 5Y3.5/1)
Case : Light gray (Munsell sign 2.5Y7.5/1)
Ambient humidity range 10 to 90% RH (non-condensing)
Rated power supply voltage 100 to 240V AC
Ambient humidity range 10 to +95% RH (non-condensing)
Vibration resistance
0 to 4.90m/s 2 (10 to 60Hz in x, Y and Z directions,
2hours each)
Allowable power supply voltage 90 to 264V AC
Power supply frequency 50
± 2Hz or 60 ± 2Hz
Vibration resistance 0 to 1.96m/s 2 (10 to 60Hz in X,Y,Z directions for 2 hours each)
Shock resistance 0 to 9.80m/s 2
Shock resistance 0 to 490m/s 2 (in vertical direction, 3 times)
Package drop test Drop height 60cm (Free drop at 1 corner, 3 edges, 6 faces)
Mounting angle Reference plane (vertical) ± 10¡
Chapter 11. SPECIFICATIONS
