Honeywell DCP552 Mark II User Manual
Page 105
7-6
Item code
Item
No.
User
settings
Settings and descriptions
Factory default
settings
PA 24
Manipulated variable
deviation limit (CH2)
24
0.1 to 110.0% OUT/0.1 sec
110.0
PA 25
Time proportional output
cycle (CH2)
25
1 to 240 sec
10
PA 26
ON-OFF control Differential
(CH2)
26
0 to 1000 SPU (CH2)
50
PA 27
PID computation initialize
manipulated variable (CH2)
27
-5.0 to 105.0%
0.0
PA 28
Unused
28
[Description:]
Ò-----Óis displayed and setting cannot be performed.
-----
PA 29
Unused
29
-----
PA 30
Unused
30
-----
PA 31
Event on delay
Group 1 event number
31
0 to 16
[Description:]
A setting of 0 generates no delay.
0
PA 32
Event on delay
Group 1 delay time
32
0.0 to 3000.0sec
[Description:]
When
PA31
is set to 0, Т-----У is displayed and setting cannot be performed.
0.0
PA 33
Event on delay
Group 2 event number
33
0 to 16
[Description:]
A setting of 0 generates no delay.
0
PA 34
Event on delay
Group 2 delay time
34
0.0 to 3000.0sec
[Description:]
When
PA33
is set to 0, Т-----У is displayed and setting cannot be performed.
0.0
PA 35
Event on delay
Group 3 event number
35
0 to 16
[Description:]
A setting of 0 generates no delay.
0
PA 36
Event on delay
Group 3 delay time
36
0.0 to 3000.0sec
[Description:]
When
PA35
is set to 0, Т------У is displayed and setting cannot be performed.
0.0
PA 37
Event on delay
Group 4 event number
37
0 to 16
[Description:]
A setting of 0 generates no delay.
0
PA 38
Event on delay
Group 4 delay time
38
0.0 to 3000.0sec
[Description:]
When
PA37
is set to 0, Т-----У is displayed and setting cannot be performed.
0.0
PA 39
FAST X
39
0
PA 40
CP computation temperature
compensation
40
-1000 to +1000 PVU (CH1)
[Description:]
Т-----У is displayed for models without CP compensation
and setting can not be performed.
0
PA 41
Unused
41
[Description:]
Ò-----Óis displayed and setting cannot be performed.
0
PA 42
Unused
42
0
PA 43
PID computation initialize
(CH1)
43
0
PA 44
PV2 message display mode
44
0: CP or PO
2
value display
1: mV value display
2: O
2
sensor impedance value display
0
PA 45
G.SOAK time (CH1)
45
0.1 to 60.0sec
2.0
PA 46
G.SOAK time (CH2)
46
0.1 to 60.0sec
2.0
0 : 2X
1 : 10X
2 : 60X
3 : 120X
[Description:]
When setup data
C62
is set to 1 (program time unit: minutes,
seconds), settings 3 and 4 produce a speed of 10 X.
When
C62
is set to 2 (program time unit: 0.1sec), the FAST
mode is not available.
0: No initialization during advance processing and PID group
change.
1: Initializes during advance processing but not during PID
group change.
2: No initialization during advance processing but initializes
during PID group change
3: Initializes both during advance processing and PID group
change
Chapter 7. PARAMETER SETUP
