4 - 8 Auxiliary Output Connection
4-10
■ Auxiliary output CH1 connection
■ Auxiliary output CH2 connection
+ -
48
+ -
49
4 to 20mA DC
Load resistance
less than 6009
Receiver
CH1
Chapter 4. WIRING
WARNING
Be sure to turn off the power supply when you connect the controller.
Failure to do so may lead to electric shock or fire.
50
+ -
51
4 to 20mA DC
Load resistance
less than 6009
Receiver
+ -
CH2
