354 Cycle programming
4.1
0
DIN cy
cles
In the DIN subprogram you can assign texts and help
graphics to the transfer values (see "Subprograms"
Chapter in the "smart.Turn- and DIN Programming“ User's
Manual).
Danger of collision!
 Cycle programming: With DIN subprograms, the zero
point shift is reset at the end of the cycle. Therefore, do
not use any DIN subprograms with zero point shifts in
cycle programming.
 In the DIN cycle, no starting point is defined. Please
keep in mind that the tool moves on a diagonal path
from the current position to the first position that is
programmed in the DIN subprogram.
