Kameleon Series Instruction Manual 127
Specifications
Analog Audio to SDI Out (MUX) 3.0 ms
AES/EBU to Analog Audio 2.5 ms @ 48 kHz
AES/EBU to AES/EBU 2.0 ms @ 48 kHz
AES/EBU to SDI Out (MUX) 3.8 ms @ 48 kHz
SDI In to SDI Out Audio Delay
(DMUX, retime, MUX) 5.6 ms
Table 25. Environmental/Power Specifications
Parameter Value
Environmental
Frame temperature range See Kameleon Frame Manual
Operating humidity range 0 to 90% non-condensing
Non-operating temperature -10 to +70 degrees C
Mechanical
Frame type 2000T1DNG Kameleon Frame or 2000T3NG Kameleon Frame
Power
Consumption KAM-AV – 14 Watts typical
KAM-SD – 11 Watts typical
KAM-ADC-S – 2 Watts typical
KAM-DAC-S – 2 Watts typical
Table 24. Electrical Length Specifications - (continued)
Parameter Value
