The ‘Zero Position’ button sets the ‘X Position’ and ‘Y Position’ parameters to 0.
The ‘Clear Crop’ button sets the ‘Top’, ‘Bottom’, ‘Left’, and ‘Right’ parameters to 0.
Position and crop values are independent. Changing one does not change the other. However,
the position controls affect the placement of the uncropped boundary of the DSK. For example,
with position (0,0) and crop values (left = 30 and top = 40), the DSK will appear to be inset from
the edge of the frame by 30 and 40 pixels.
The amount of crop is indicated by a light grey field.
‘Options Saving’
This is the ‘Options Saving’ sub-menu:
In this menu, you can save the settings of the currently selected DSK. Press ‘Save DSK Settings’ to
do so.
S If you have cleared the DSK, the ‘Save DSK Settings’ button is absent.
The ‘Main Menu’ button returns you to the main menu.
The ‘Rates, CGT, Keying’ button takes you to the ‘Rates, CGT, Keying’ sub-menu.
The ‘Position Size Crop’ button takes you to the ‘Position, Size, Crop’ sub-menu.
The ‘Browse’ button takes you back to the DSK browser.
