Manufacturer contact: http://www.planar.com
Also see the following drawings.
Drawings
The following drawings identify features and provide overall and critical dimensions.
Fig. 7-2: Planar PT1945R Touchscreen Display, Front View, with Stand
15.39
[390.85]
14.05
[356.80]
17.00 [431.8]
