Installation
Connections
Connections
These are the connectors at the rear of the button panel:
These are the connectors in the wiring recess of the display unit:
GPI / Alarms
The GPI / Alarms connector of the button panel supports optional or discretionary wiring. The
connector is a DB25. See Specifications on page 158 for pinout and usage information.
DC Power (2)
Ethernet Ethernet
VGA
USB (2)
USB RS232 VGA AUDIO
AC Input VGA Port
Audio Jack
USB Port
RS-232 Port
On/Off
Switch
