Part No. Description Fig. Ref.
RS5-1207-020CN Bushing, Plastic 8-07 65
RS5-2463-000CN Compression Spring, Front 8-04D 14
RS5-2466-000CN Compression Spring, Rear 8-04D 16
RS5-2490-000CN Tension Spring 8-04A 20
RS5-2556-000CN Spring 8-07 63
RS5-8596-000CN Label, Operation (Special Order) 8-02 04
RS5-8605-000CN Paper Size Guide Label (Trays 2 and 3) 8-01 not shown
RS5-8611-000CN Cassette Size Labels 8-07 30
VD5-0056-301CN Fuse, LVPS, 110-120V 8-06 05
VD7-0643-151CN Power Supply Fuse 8-08 27
VD7-0646-301CN Fuse, LVPS, Universal 8-06 05A
VS1-5057-007CN Connector, 7P 8-06 13A
WG8-0291-000CN Photo Interrupter 8-04D 18
WG8-0291-000CN Photo Interrupter 8-04E 52
WG8-5210-000CN Paper Reg. Sensor 8-07 64
XA9-0267-000CN Screw, TP, M3X6 (fixed shoulder) 8-02 CH101
XA9-0267-000CN Screw, TP, M3X6 (fixed shoulder) 8-03 CH101
XA9-0267-000CN Screw, TP, M3X6 (fixed shoulder) 8-05 CH101
XA9-0267-000CN Screw, TP, M3X6 (fixed shoulder) 8-06 CH101
XA9-0547-000CN Screw, TP, M3X6 (floating flat and lock washer) 8-02 CH102
XA9-0547-000CN Screw, TP, M3X6 (floating flat and lock washer) 8-03 CH102
XA9-0605-000CN Screw, tapping, M4X8 8-03 CH114
XA9-0817-000CN Screw, w/washer, M3X20 8-03 CH105
XA9-0817-000CN Screw, w/washer, M3X20 8-05 CH105
XB4-7300-809CN Screw, tapping, truss head, M3X8 8-05 CH106
XB4-7401-009CN Screw, tapping, pan head, M4X10 8-02 CH107
XB4-7401-009CN Screw, tapping, pan head, M4X10 8-05 CH107
XB5-7303-007CN Screw, CT, M3X3 8-05 CH104
XB5-7303-007CN Screw, CT, M3X3 8-06 CH104
XB6-7300-607CN Screw, TP, M3X6 8-07 CH110
XB6-7300-607CN Screw, TP, M3X6 8-08 CH110
XB6-7400-606CN Screw, TP, M4X6 8-07 CH108
XB6-7400-606CN Screw, TP, M4X6 8-08 CH108
XB6-7400-607CN Screw, TP, M4X6 8-07 CH109
Table A-2 Numerical Parts Index (continued)
A-18 Parts Index
