Front Cover
1 Open all access doors and remove the Duplex Unit if installed.
2 Open front access door and remove (3) screws, CH102 (Figure 6-5, callout 1).
3 Open the Diverter Access Door and release the two plastic retaining tabs
inside the Duplex Unit cavity (Figure 6-6, callout 2).
C a u t i o n Be careful, the plastic upper retaining tabs will break off if the cover is
tilted too far out.
4 Carefully pull the bottom of the cover away from the chassis while moving it
to the right to release the retaining tab (Figure 6-5, callout 3).
5 Carefully tilt the bottom edge of the cover away from the chassis to release
the upper retaining tabs.
6-20 Removal and Replacement
