Ref
Description
Part Number
QTY
01
2000-Sheet Input Tray Assembly
RG5-2155-000CN
1
02
Front Cover
RF5-1632-000CN
1
03
Right Cover
RB1-7832-000CN
1
04
Left Cover
RB1-7833-000CN
1
05
Back Cover
RB1-7834-000CN
1
15
Cassette Size Plate
RB1-6894-000CN
1
30
Cassette Size Labels
RS5-8611-000CN
1
31
Motor Cable
RG5-2233-000CN
1
50
Tray 4 Main Drive Assembly
RG5-2164-030CN
1
51
Paper Pick-Up Assembly
RG5-2170-000CN
1
52
Feed / Separation Rollers
RF5-1426-000CN
2
53
Pickup Roller
RF5-1427-000CN
1
54
Torque Limiter
RB1-6588-000CN
1
60
Vertical Transfer Assembly
RG5-2175-020CN
1
61
Paper Registration Sensor Flag
RB1-7813-000CN
1
62
Paper Reg- Bushing
RS5-1201-000CN
1
63
Spring
RS5-2556-000CN
1
64
Paper Reg. Sensor
WG8-5210-000CN
1
65
Bushing, Plastic
RS5-1207-020CN
1
66
Lifter Sensing Switch (SW31)
RG5-2546-000CN
1
67
Adjustable Size Plate: Back
RF5-1609-000CN
1
68
Adjustable Size Plate: Middle
RB1-7726-000CN
1
69
Adjustable Size Plate: Front
RF5-1623-000CN
1
CH108
Screw, TP, M4X6
XB6-7400-606CN
67
CH109
Screw, TP, M4X6
XB6-7400-607CN
2
CH110
Screw, TP, M3X6
XB6-7300-607CN
2
Table 8-7
2000-Sheet Input Unit Internal Components
8
Parts and
Diagrams
Parts and Diagrams 8-21
