Fig
Ref
Description
Part
Qty
8-04
A
Diverter Assembly
RG9-1150-000CN
8-04A
11
Diverter Drive Assembly
RF5-1441-000CN
1
8-04A
16
20T Gear
RS5-0758-000CN
1
8-04A
18
Conductive Bushing
RS5-1101-000CN
1
8-04A
20
Tension Spring
RS5-2490-000CN
1
8-04B
11
Paper Sensing Lever
RB1-6692-000CN
1
8-04B
12
Paper Height Lever
RB1-6693-000CN
1
8-04B
25
Fan 4
RH7-1289-000CN
1
8-04
C
Fuser Assembly 110V, Exchange
C3166-69001
8-04
C
Fusing Assembly 220-240V, Exchange
C3166-69013
8-04C
36
Fuser Flag
RB1-6614-000CN
1
8-04C
37
Fuser Lock Lever Right
RB1-6615-000CN
1
8-04C
38
Fuser Lock Lever Left
RB1-6616-000CN
1
8-04
D
Feeder Assembly
RG5-1834-000CN
8-04D
03
Sensor Arm Spring
RB1-6409-000CN
1
8-04D
07
Block, Shaft Holding, Front
RB1-6414-000CN
1
8-04D
08
Block, Shaft Holding, Rear
RB1-6415-000CN
1
8-04D
10
Sensor Arm PS1
RB1-6417-000CN
1
8-04D
13
Sensor Cable
RG5-1843-000CN
1
8-04D
14
Compression Spring, Front
RS5-2463-000CN
1
8-04D
16
Compression Spring, Rear
RS5-2466-000CN
1
8-04D
18
Photo Interrupter
WG8-0291-000CN
1
8-04
E
Paper Input Unit (PIU)
C3166-69011
8-04E
10
Torque Limiter
RB1-6588-000CN
2
8-04E
103
PIU PCA
RG5-1860-000CN
1
8-04E
20
Feed / Separation Rollers
RF5-1426-000CN
4
8-04E
21
Pickup Roller
RF5-1427-000CN
2
8-04E
48
Sensor Arm PS2
RB1-6557-000CN
1
8-04E
49
Sensor Arm Spring
RB1-6558-000CN
1
8-04E
51
Sensor Cable
RG5-1859-000CN
1
8-04E
52
Photo Interrupter
WG8-0291-000CN
1
8-04E
86
Paper Pickup Cable
RG5-1861-000CN
1
8-04E
87
Pick-Up Motor
RH7-1262-000CN
1
Table 8-4
Printer Internal Components (2 of 4)
