EXP Computer C4077-90960 - Manual (Page 335)

1
2
3
4
5
6
7
8
9
10
Vcc
Vcc
Vcc
1
2
3
1
2
3
4
1
2
1
2
3
4
5
1716151413121110 9 8 7 6 5 4 3 2 1
previous
device
connector
(in)
CLINK
next
device
connector
(out)
CLINK
power
supply
connector
(one dot)
(two dots)
M5 Decoder
M2
M1
M4 M3
Delivery Head
Roller Motor
Ejector Motor
Delivery Head
Position Motor
Flipper
Roller Motor
Transport Belt Motor
PS BELT
INTERLOCK SWITCH
PS FUFULL
PS FACEUP
PS ENTRY
PS BIN EMPTY
PS EXIT 2
PS BIN FULL / HEAD POSITION
PS EXIT 1
PS EJECT
MULTI-BIN
MAILBOX
CONTROLLER
PCA
/TX
/RX
/TERMINATE OUT
/CLOCK
/STROBE
POWER ON IN
GND
24 V
/TX
/RX
/TERMINATE IN
/CLOCK
/STROBE
POWER ON OUT
GND
24 V
1
3
4
6
12
13
2-7-8-11
5-10
1
3
4
6
12
13
2-7-8-11
5-10
5
10
15
1
6
11
24 V
J7
J2
J3
J6
J5
J4
J8
J9
J10
Figure 7-39 Multi-Bin Mailbox Main Wiring Diagram
7-98 Troubleshooting
