Ref
Description
Part Number
QTY
01
Flipper Assembly (no cable)
C3764-60501
1
02
Mounting Shaft (Hex)
C3764-60516
1
03
Jam Access Door Assembly
C3764-60514
1
04
Spring, left, jam access door
C3764-60522
1
05
Metal Tape Holder
C3764-60515
1
06
Spring, right, jam access door
C3764-60518
1
07
Mounting Shaft "e" Clip
C3764-60517
2
08
Metallic Tape and Housing Assy.
C3764-60521
1
09
Delivery Head Assembly for Multi-Bin Mailbox
Delivery Head Assembly for Mailbox with Stapler
C3764-60502
C3766-60514
1
10
Anti-Curl String
C3764-60562
2
11
Lower Pulley Assembly
C3764-60530
2
12
Lower Pulley Spring
C3764-60531
2
13
Anti-Curl String Spring
C3764-60563
2
14
Pulley, small
C3764-60564
2
CH111
Screw, Torx, T20, M4X12
C3764-60520
2
not shown
Metallic Tape/Housing Kit includes: Metal Tape Holder,
C3764-60515; Metallic Tape & Housing Assy, C3764-60521
C3764-67900
not shown
Hardware Kit includes: Mounting Shaft ‘e’ Clip 5,
C3764-60517; L Spring Right, C3764-60518; L Spring
Left, C3764-60522; Mount Screw Machined T20 M4X10,
C3764-60519; Plastic Spacer, C3764-60524; Mount
Screw Machined T20 M4X12, C3764-60520; Gasket
Cable Clamps, C3764-60565; Lower Pulley Assembly,
C3764-60530; Lower Pulley Spring, C3764-60531; PCA
Mounting Screw, C3764-60525
C3764-67901
not shown
Paper Guide Kit includes: Paper Guide String,
C3764-60562; Paper Guide Spring, C3764-60563; Pulley
(small), C3764-60564
C3764-67902
not shown
Flat Cable Kit Includes: Flat Cable, C3764-60545; Cable
Holder (flat),C3764-60513; Cable Holder (edge),
C3764-60566
C3764-67903
not shown
Stepper Motor/Encoder Kit includes: Transport Stepper
Motor Assy, C3764-60532; Encoder Assy, C3764-60533;
Encoder Cable, C3764-60549
C3764-67904
not shown
Interlock Switch Kit includes: Interlock Switch,
C3764-60556; Interlock Switch Cable, C3764-60548
C3764-67905
not shown
Attachment Beam Kit includes: Attachment Beam Assy,
C3764-60558; Attachment Clips, C3764-60559;
Attachment Bracket, C3764-60560
C3764-67906
Table 8-10
Multi-Bin Mailbox/Mailbox with Stapler Components (2 of 3)
