rletech.com LD5200 User Guide 91
5 Modbus Communication
30024 Modbus Zone7 Distance Location of leak Ft/Meters 0-65535
30025 Modbus Zone8 Status Bit Level Status None 0-65535
30026 Modbus Zone8 Distance Location of leak Ft/Meters 0-65535
30027 Modbus Zone9 Status Bit Level Status None 0-65535
30028 Modbus Zone9 Distance Location of leak Ft/Meters 0-65535
30029 Modbus Zone10 Status Bit Level Status None 0-65535
30030 Modbus Zone10 Distance Location of leak Ft/Meters 0-65535
30031 Modbus Zone11 Status Bit Level Status None 0-65535
30032 Modbus Zone11 Distance Location of leak Ft/Meters 0-65535
30033 Modbus Zone12 Status Bit Level Status None 0-65535
30034 Modbus Zone12 Distance Location of leak Ft/Meters 0-65535
30035 Modbus Zone13 Status Bit Level Status None 0-65535
30036 Modbus Zone13 Distance Location of leak Ft/Meters 0-65535
30037 Modbus Zone14 Status Bit Level Status None 0-65535
30038 Modbus Zone14 Distance Location of leak Ft/Meters 0-65535
30039 Modbus Zone15 Status Bit Level Status None 0-65535
30040 Modbus Zone15 Distance Location of leak Ft/Meters 0-65535
30041 Modbus Zone16 Status Bit Level Status None 0-65535
30042 Modbus Zone16 Distance Location of leak Ft/Meters 0-65535
30043 Modbus Zone Enabled Flags
(00=Modbus Zone 17...
15=Modbus Zone 32)
Bit Level Status
Modbus Zone 17 through
Modbus Zone 32
None 0-65535
30044 Modbus Zone17 Status Bit Level Status None 0-65535
30045 Modbus Zone17 Distance Location of leak Ft/Meters 0-65535
30046 Modbus Zone18 Status Bit Level Status None 0-65535
30047 Modbus Zone18 Distance Location of leak Ft/Meters 0-65535
30048 Modbus Zone19 Status Bit Level Status None 0-65535
30049 Modbus Zone19 Distance Location of leak Ft/Meters 0-65535
30050 Modbus Zone20 Status Bit Level Status None 0-65535
30051 Modbus Zone20 Distance Location of leak Ft/Meters 0-65535
30052 Modbus Zone21 Status Bit Level Status None 0-65535
30053 Modbus Zone21 Distance Location of leak Ft/Meters 0-65535
30054 Modbus Zone22 Status Bit Level Status None 0-65535
30055 Modbus Zone22 Distance Location of leak Ft/Meters 0-65535
30056 Modbus Zone23 Status Bit Level Status None 0-65535
30057 Modbus Zone23 Distance Location of leak Ft/Meters 0-65535
30058 Modbus Zone24 Status Bit Level Status None 0-65535
Register Name Description Units Range
Table 5.5 Input Registers (continued)
