Z8
®
CPU
User Manual
UM001604-0108 Instruction Description
167
Clear
Syntax
CLR dst
Instruction Format
Operation
dst
←
0
The destination operand is cleared to
00h
.
Address modes R or IR can be used to specify a 4-bit Working Register. In this format, the
destination Working Register operand is specified by adding
1110b
(
Eh
) to the high nibble
of the operand. For example, if Working Register R12 (CH) is the destination operand, then
ECh
is used as the destination operand in the Op Code.
Example
If Working Register R6 contains AFh, the statement:
CLR R6
Op Code: B0 E6
leaves the value
00h
in Working Register R6.
If Register
A5h
contains the value
23h
, and Register
23h
contains the value
FCh
, the state-
ment:
CLR @A5h
Op Code: B1 A5
leaves the value
00h
in Register
23h
.
Cycles
OPC
(Hex)
Address
dst
OPC dst
6 B0 R
6 B1 IR
Flag Description
C Unaffected
Z Unaffected
S Unaffected
V Unaffected
D Unaffected
H Unaffected
E dst
Note:
