Z8

®

CPU

User Manual

UM001604-0108

Interrupts

106

Figure 100. Effects of an Interrupt on the Stack

SP

Top of Stack

PC LOW Byte

PC HIGH Byte

FLAGS

SP and Stack after an interrupt

SP

SP and Stack before an interrupt
