E24 FMC_HB_P5 AE13 2.5-V CMOS FMC data bus HPC bank B
K28 FMC_HB_P6 AG12 2.5-V CMOS FMC data bus HPC bank B
J27 FMC_HB_P7 AH11 2.5-V CMOS FMC data bus HPC bank B
F28 FMC_HB_P8 AR10 2.5-V CMOS FMC data bus HPC bank B
E27 FMC_HB_P9 AM10 2.5-V CMOS FMC data bus HPC bank B
K31 FMC_HB_P10 AD13 2.5-V CMOS FMC data bus HPC bank B
J30 FMC_HB_P11 AW9 2.5-V CMOS FMC data bus HPC bank B
F31 FMC_HB_P12 AV10 2.5-V CMOS FMC data bus HPC bank B
E30 FMC_HB_P13 AU9 2.5-V CMOS FMC data bus HPC bank B
K34 FMC_HB_P14 AR13 2.5-V CMOS FMC data bus HPC bank B
J33 FMC_HB_P15 AJ12 2.5-V CMOS FMC data bus HPC bank B
F34 FMC_HB_P16 AP12 2.5-V CMOS FMC data bus HPC bank B
K37 FMC_HB_P17 AD11 2.5-V CMOS FMC data bus HPC bank B
J36 FMC_HB_P18 AE12 2.5-V CMOS FMC data bus HPC bank B
E33 FMC_HB_P19 AU12 2.5-V CMOS FMC data bus HPC bank B
F37 FMC_HB_P20 AL12 2.5-V CMOS FMC data bus HPC bank B
E36 FMC_HB_P21 AM13 2.5-V CMOS FMC data bus HPC bank B
D30 FMC_JTAG_TDI — 2.5-V CMOS JTAG data in
D31 FMC_JTAG_TDO — 2.5-V CMOS JTAG data out
D33 FMC_JTAG_TMS — 2.5-V CMOS JTAG mode select
G7 FMC_LA_N0 AN16 2.5-V CMOS FMC data bus LPC bank A
D9 FMC_LA_N1 AV13 2.5-V CMOS FMC data bus LPC bank A
H8 FMC_LA_N2 AT15 2.5-V CMOS FMC data bus LPC bank A
G10 FMC_LA_N3 AW14 2.5-V CMOS FMC data bus LPC bank A
H11 FMC_LA_N4 AK8 2.5-V CMOS FMC data bus LPC bank A
D12 FMC_LA_N5 AN7 2.5-V CMOS FMC data bus LPC bank A
C11 FMC_LA_N6 AL9 2.5-V CMOS FMC data bus LPC bank A
H14 FMC_LA_N7 AU6 2.5-V CMOS FMC data bus LPC bank A
G13 FMC_LA_N8 AN9 2.5-V CMOS FMC data bus LPC bank A
D15 FMC_LA_N9 AG17 2.5-V CMOS FMC data bus LPC bank A
C15 FMC_LA_N10 AV7 2.5-V CMOS FMC data bus LPC bank A
H17 FMC_LA_N11 AK15 2.5-V CMOS FMC data bus LPC bank A
G16 FMC_LA_N12 AJ16 2.5-V CMOS FMC data bus LPC bank A
D18 FMC_LA_N13 AK14 2.5-V CMOS FMC data bus LPC bank A
C19 FMC_LA_N14 AT13 2.5-V CMOS FMC data bus LPC bank A
H20 FMC_LA_N15 AL16 2.5-V CMOS FMC data bus LPC bank A
G19 FMC_LA_N16 AK24 2.5-V CMOS FMC data bus LPC bank A
D21 FMC_LA_N17 AN15 2.5-V CMOS FMC data bus LPC bank A
Table 2–29. FMC Connector Pin Assignments, Schematic Signal Names, and Functions (Part 5 of 7)
Board
Reference
(J10)
Schematic
Signal Name
Arria V GT
FPGA
Pin Number
I/O Standard Description
