2–38 Chapter 2: Board Components
Memory
Cyclone V GT FPGA Development Board September 2014 Altera Corporation
Reference Manual
R8 DDR3A_A6 AK17 1.5-V SSTL Class I Address bus
R2 DDR3A_A7 AL17 1.5-V SSTL Class I Address bus
T8 DDR3A_A8 AH16 1.5-V SSTL Class I Address bus
R3 DDR3A_A9 AJ16 1.5-V SSTL Class I Address bus
L7 DDR3A_A10 AL16 1.5-V SSTL Class I Address bus
R7 DDR3A_A11 AM16 1.5-V SSTL Class I Address bus
N7 DDR3A_A12 AM13 1.5-V SSTL Class I Address bus
T3 DDR3A_A13 AN13 1.5-V SSTL Class I Address bus
M2 DDR3A_BA0 AN16 1.5-V SSTL Class I Bank address bus
N8 DDR3A_BA1 AN17 1.5-V SSTL Class I Bank address bus
M3 DDR3A_BA2 AP17 1.5-V SSTL Class I Bank address bus
K3 DDR3A_CASN AP15 1.5-V SSTL Class I Row address select
K9 DDR3A_CKE AP26 1.5-V SSTL Class I Column address select
J7 DDR3A_CLK_P AA18
Differential 1.5-V SSTL
Class I
Differential output clock
K7 DDR3A_CLK_N AA17
Differential 1.5-V SSTL
Class I
Differential output clock
L2 DDR3A_CSN AA16 1.5-V SSTL Class I Chip select
E7 DDR3A_DM0 AL21 1.5-V SSTL Class I Write mask byte lane
D3 DDR3A_DM1 AM24 1.5-V SSTL Class I Write mask byte lane
E3 DDR3A_DQ0 AN19 1.5-V SSTL Class I Data bus byte lane 0
F7 DDR3A_DQ1 AM19 1.5-V SSTL Class I Data bus byte lane 0
F2 DDR3A_DQ2 AP20 1.5-V SSTL Class I Data bus byte lane 0
F8 DDR3A_DQ3 AP21 1.5-V SSTL Class I Data bus byte lane 0
H3 DDR3A_DQ4 AH19 1.5-V SSTL Class I Data bus byte lane 0
H8 DDR3A_DQ5 AG19 1.5-V SSTL Class I Data bus byte lane 0
G2 DDR3A_DQ6 AJ19 1.5-V SSTL Class I Data bus byte lane 0
H7 DDR3A_DQ7 AM21 1.5-V SSTL Class I Data bus byte lane 0
D7 DDR3A_DQ8 AM20 1.5-V SSTL Class I Data bus byte lane 1
C3 DDR3A_DQ9 AL20 1.5-V SSTL Class I Data bus byte lane 1
C8 DDR3A_DQ10 AN22 1.5-V SSTL Class I Data bus byte lane 1
C2 DDR3A_DQ11 AN23 1.5-V SSTL Class I Data bus byte lane 1
A7 DDR3A_DQ12 AP24 1.5-V SSTL Class I Data bus byte lane 1
A2 DDR3A_DQ13 AP25 1.5-V SSTL Class I Data bus byte lane 1
B8 DDR3A_DQ14 AN26 1.5-V SSTL Class I Data bus byte lane 1
A3 DDR3A_DQ15 AN24 1.5-V SSTL Class I Data bus byte lane 1
F3 DDR3A_DQS_P0 AB19
Differential 1.5-V SSTL
Class I
Data strobe P byte lane 0
G3 DDR3A_DQS_N0 AC19
Differential 1.5-V SSTL
Class I
Data strobe N byte lane 0
Table 2–28. DDR3A Device Pin Assignments, Schematic Signal Names, and Functions (Part 2 of 5)
Board Reference
Schematic
Signal Name
Cyclone V GT
Pin Number
I/O Standard Description
