Chapter 2: Board Components 2–31
Components and Interfaces
September 2014 Altera Corporation Cyclone V GT FPGA Development Board
Reference Manual
107 HSMA_TX_D_P9 B10 LVDS or 2.5-V LVDS TX bit 9 or CMOS bit 44
108 HSMA_RX_D_P9 F15 LVDS or 2.5-V LVDS RX bit 9 or CMOS bit 45
109 HSMA_TX_D_N9 A10 LVDS or 2.5-V LVDS TX bit 9n or CMOS bit 46
110 HSMA_RX_D_N9 G15 LVDS or 2.5-V LVDS RX bit 9n or CMOS bit 47
113 HSMA_TX_D_P10 B13 LVDS or 2.5-V LVDS TX bit 10 or CMOS bit 48
114 HSMA_RX_D_P10 E18 LVDS or 2.5-V LVDS RX bit 10 or CMOS bit 49
115 HSMA_TX_D_N10 A13 LVDS or 2.5-V LVDS TX bit 10n or CMOS bit 50
116 HSMA_RX_D_N10 E17 LVDS or 2.5-V LVDS RX bit 10n or CMOS bit 51
119 HSMA_TX_D_P11 C11 LVDS or 2.5-V LVDS TX bit 11 or CMOS bit 52
120 HSMA_RX_D_P11 G13 LVDS or 2.5-V LVDS RX bit 11 or CMOS bit 53
121 HSMA_TX_D_N11 B11 LVDS or 2.5-V LVDS TX bit 11n or CMOS bit 54
122 HSMA_RX_D_N11 H13 LVDS or 2.5-V LVDS RX bit 11n or CMOS bit 55
125 HSMA_TX_D_P12 C14 LVDS or 2.5-V LVDS TX bit 12 or CMOS bit 56
126 HSMA_RX_D_P12 E14 LVDS or 2.5-V LVDS RX bit 12 or CMOS bit 57
127 HSMA_TX_D_N12 B14 LVDS or 2.5-V LVDS TX bit 12n or CMOS bit 58
128 HSMA_RX_D_N12 D14 LVDS or 2.5-V LVDS RX bit 12n or CMOS bit 59
131 HSMA_TX_D_P13 F13 LVDS or 2.5-V LVDS TX bit 13 or CMOS bit 60
132 HSMA_RX_D_P13 C16 LVDS or 2.5-V LVDS RX bit 13 or CMOS bit 61
133 HSMA_TX_D_N13 E13 LVDS or 2.5-V LVDS TX bit 13n or CMOS bit 62
134 HSMA_RX_D_N13 B16 LVDS or 2.5-V LVDS RX bit 13n or CMOS bit 63
137 HSMA_TX_D_P14 A17 LVDS or 2.5-V LVDS TX bit 14 or CMOS bit 64
138 HSMA_RX_D_P14 D17 LVDS or 2.5-V LVDS RX bit 14 or CMOS bit 65
139 HSMA_TX_D_N14 A16 LVDS or 2.5-V LVDS TX bit 14n or CMOS bit 66
140 HSMA_RX_D_N14 D16 LVDS or 2.5-V LVDS RX bit 14n or CMOS bit 67
143 HSMA_TX_D_P15 B15 LVDS or 2.5-V LVDS TX bit 15 or CMOS bit 68
144 HSMA_RX_D_P15 L16 LVDS or 2.5-V LVDS RX bit 15 or CMOS bit 69
145 HSMA_TX_D_N15 A15 LVDS or 2.5-V LVDS TX bit 15n or CMOS bit 70
146 HSMA_RX_D_N15 L15 LVDS or 2.5-V LVDS RX bit 15n or CMOS bit 71
149 HSMA_TX_D_P16 C18 LVDS or 2.5-V LVDS TX bit 16 or CMOS bit 72
150 HSMA_RX_D_P16 F17 LVDS or 2.5-V LVDS RX bit 16 or CMOS bit 73
151 HSMA_TX_D_N16 C17 LVDS or 2.5-V LVDS TX bit 16n or CMOS bit 74
152 HSMA_RX_D_N16 F16 LVDS or 2.5-V LVDS RX bit 16n or CMOS bit 75
155 HSMA_CLK_OUT_P2 B18 LVDS or 2.5-V LVDS or CMOS clock out 2 or CMOS bit 76
156 HSMA_CLK_IN_P2 H17 LVDS or 2.5-V LVDS or CMOS clock in 2 or CMOS bit 77
157 HSMA_CLK_OUT_N2 A18 LVDS or 2.5-V LVDS or CMOS clock out 2 or CMOS bit 78
158 HSMA_CLK_IN_N2 H16 LVDS or 2.5-V LVDS or CMOS clock in 2 or CMOS bit 79
160 HSMA_PRSNTn L11 2.5-V CMOS HSMC port A presence detect
HSMC Port B (J2)
17 HSMB_TX_P3 F4 1.5-V PCML Transceiver TX bit 3
Table 2–22. HSMC Interface Pin Assignments, Schematic Signal Names, and Functions (Part 3 of 6)
Board
Reference
Schematic Signal Name
Cyclone V GT
Pin Number
I/O Standard Description
