Page 85
0.440
0.900
R0.220
1.300
1.492
1.520
0.354 THRU
0.614 X 90°
X 9 PLACES
0.354 THRU
R0.300 MINIMUM
FLAT SURFACE
1.320
8.800
4.390 TYP.
5.118
2.559
USE BALL NOSED END MILL TO MACHINE
0.175
ADD RADIUS OR CHAM.
ADD RADIUS OR CHAM.
ABZ
12/23/11
N/A
0
1:1
N/A N/A
C5 E-FORCE VALLEY TRAY MODIFICATION
N/A
SCALE: SIZE
DWG. NO.
A
REV.
MATERIAL FINISH
DO NOT SCALE DRAWING
APPLICATION
USED ON
NEXT ASSY
DIMENSIONS ARE IN INCHES TOLERANCES: ANGULAR: MACH
0.5
ONE PLACE DECIMAL
0.2*
TWO PLACE DECIMAL
0.01*
THREE PLACE DECIMAL
0.005*
*UNLESS STATED OTHERWISE
NAME
DATE
DRAWN CHECKED ENG APPR. MFG APPR. Q.A.
SHEET 1 OF 1
WEIGHT:
COMMENTS:
REVISIONS
DESCRIPTION
REV.
DATE
APPROVED
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF LINGENFELTER PERFORMACE ENGINEERING. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF LINGENFELTER PERFORMACE ENGINEERING IS PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
DWG. NAME
NOTES: 1. ALL CUTTING DEPTHS ARE
0.050"
Diagram 2
