Lingenfelter L250280197 Lingenfelter C5 Corvette E-Force Supercharger Install Kit v2.9 - Manual (Page 18)

Page 17
33. Using a 15mm socket and ratchet, rotate
the belt tensioner clockwise to relieve the tension
from the belt. Remove the belt from the tensioner
pulley.
CAUTION: Take care not to pinch your fingers
between the pulley and the belt.
34. Using a 13mm socket and ratchet, remove
the positive wire from the alternator. Disconnect
the alternator wiring harness electrical connector.
35. Using a 15mm socket and ratchet, remove
the alternator from the mounting bracket by
removing the two (2) bolts indicated.
36. With a twisting and pulling
motion, disconnect the spark plug wires
from each coil pack, There are four
(4) wires on each side, eight (8) total.
NOTE: Inspect the spark plug wires and replace
if necessary.
