Page 2
# Description Item ID/PN
2 Coolant bleed plug 12602048
3 Vacuum line hose, 4mm (quantity in linear feet) HT-21503-10
1 Oil pressure sensor relocation fitting XX04468-0001
1 Banjo bolt, 16mm XX04468-0005
2 Banjo bolt sealing washer, 16mm 1501116
1 button head valley tray fastener M8 X 1.25 X 15 M7380A2-8x25
1 Solenoid Bracket 12577830
1 3/8” X 31/32” cap, passenger rear port on valve cover AV12210
2 Air intake spacer XX04468-0002
2 M8 X 1.25 X 40mm fully threaded button head cap screw 92095A294
2 M8 X 1.25 nut 47385
2 M8 Nylock nut 41754
2 Black plastic nut cap APP1HDC31202
1 1/4 hose union, stainless (to bypass throttle body coolant) 5670K11
1 3-7/8” angle cut inlet hose XX04468-0022
1 Intercooler pump harness XX04468-0011
1 MAP/IAT adapter harness XX04468-0012
1 MAF adapter harness, 5 pin to 3 pin, 1997-2000 XX04468-0013
1 MAF adapter harness, 5 pin to 5 pin, 2001-2004 XX04468-0014
1 C5 TPS 22" extension harness L480060197
1 Throttle body motor extension harness, 8" CE105320
1 LS2 throttle body gasket 12576549
3 M6-1x30mm socket head cap screw, stainless steel 47536
1 M6-1x55mm socket head cap screw, stainless steel MS2550055A20000
6 M6 stainless washer 47393
1 PCV fresh air hose to pass valve cover 15739LPE
2 1/4" spacer for sub frame, v1 XX04468-0003
2 1/4" spacer for sub frame, v2 XX04468-0004
1 Intercooler fluid reservoir XX04468-0015
1 Intercooler reservoir bracket XX04468-0010
1 Fender washer for intercooler reservoir bracket 91116A150
1 M6-1x16 hex head bolt, stainless steel 47313
2 Aluminum unthreaded spacer 3/4" OD, 3/4" length, 5/16" screw size 92510A804
2 M6-1.0x35 M6 bolt AV21049
1 90 degree 3/4” hose, 36” leg 9820
1 2-1/4” Adel clamp DC-2036
6 1/4” washer, stainless 30800
1 1/4-28 lock nut 63546
1 1/4-28x1 bolt 36304
LPE C5 E-Force Installation Kit Parts List
(PN: L250280197)
