i.LON SmartServer 2.0 Programmer’s Reference

6-11

Offset Limit

Alarm Generated When....

Alarm Status

Input Value>Compare Value +
UCPThighLimit1Offset

AL_HIGH_LMT_ALM1

Input Value>Compare Value +
UCPThighLimit2Offset

AL_HIGH_LMT_ALM2

Input ValueUCPTlowLimit1Offset

AL_LOW_LMT_ALM1

Input ValueUCPTlowLimit2Offset

AL_LOW_LMT_ALM2

Each time an alarm is generated based on any of these offset limits, the value of the input data point
must return to a value inside the hysteresis range for that limit, and the time period specified by the
property must elapse, before the alarm is cleared. Only then could another alarm be
generated based on that offset limit.

The Alarm Generator’s hysteresis levels determine the value the input data point must return to for
each alarm condition to be cleared. The following table describes how these levels are calculated for
each of the offset limits listed above.

Offset Limit Causing Alarm

Alarm Cleared When...

Input Value<=Comp Value+ UCPThighLimit1Offset –
SCPThysHigh1

Input Value<=Comp Value+ UCPThighLimit2Offset –
SCPThysHigh2

Input Value>= Compare Value – UCPTlowLimit1Offset +
SCPThysLow1

Input Value>= Compare Value – UCPTlowLimit2Offset +
SCPThysLow2

When an alarm is cleared, the data point is updated to the next lowest alarm level. For example, when
an AL_LOW_LMT_ALM_2 alarm is cleared, the data point is updated to AL_LOW_LMT_ALM_1.
When that condition clears, the data point is updated to AL_NO_CONDITION. The following table
describes this process in more detail.

Event

Input Data Point Status

Comments

Value of input data point is
normal.

AL_NO_CONDITION

No alarm condition.

Value of input data point
goes above first level
(UCPThighLimit1Offset).

AL_HIGH_LMT_ALM1

Updated to the first alarm
condition.

Value of input data point
goes above second level
(UCPThighLimit2Offset).

AL_HIGH_LMT_ALM2

Updated to the second, and more
severe, alarm condition.
