Table 102 — Suction Pressure Transducer Pressure (PSIG) vs. Voltage (SP-A, SP-B, SP.XR = 1,
48/50AJ,AK,AW,AY Units Only)
PRESSURE
(PSIG)
VOLTAGE
DROP (V)
PRESSURE
(PSIG)
VOLTAGE
DROP (V)
PRESSURE
(PSIG)
VOLTAGE
DROP (V)
PRESSURE
(PSIG)
VOLTAGE
DROP (V)
0
0.500
51
1.520
101
2.520
151
3.520
1
0.520
52
1.540
102
2.540
152
3.540
2
0.540
53
1.560
103
2.560
153
3.560
3
0.560
54
1.580
104
2.580
154
3.580
4
0.580
55
1.600
105
2.600
155
3.600
5
0.600
56
1.620
106
2.620
156
3.620
6
0.620
57
1.640
107
2.640
157
3.640
7
0.640
58
1.660
108
2.660
158
3.660
8
0.660
59
1.680
109
2.680
159
3.680
9
0.680
60
1.700
110
2.700
160
3.700
10
0.700
61
1.720
111
2.720
161
3.720
11
0.720
62
1.740
112
2.740
162
3.740
12
0.740
63
1.760
113
2.760
163
3.760
13
0.760
64
1.780
114
2.780
164
3.780
14
0.780
65
1.800
115
2.800
165
3.800
15
0.800
66
1.820
116
2.820
166
3.820
16
0.820
67
1.840
117
2.840
167
3.840
17
0.840
68
1.860
118
2.860
168
3.860
18
0.860
69
1.880
119
2.880
169
3.880
19
0.880
70
1.900
120
2.900
170
3.900
20
0.900
71
1.920
121
2.920
171
3.920
21
0.920
72
1.940
122
2.940
172
3.940
22
0.940
73
1.960
123
2.960
173
3.960
23
0.960
74
1.980
124
2.980
174
3.980
24
0.980
75
2.000
125
3.000
175
4.000
25
1.000
76
2.020
126
3.020
176
4.020
26
1.020
77
2.040
127
3.040
177
4.040
27
1.040
78
2.060
128
3.060
178
4.060
28
1.060
79
2.080
129
3.080
179
4.080
29
1.080
80
2.100
130
3.100
180
4.100
30
1.100
81
2.120
131
3.120
181
4.120
31
1.120
82
2.140
132
3.140
182
4.140
32
1.140
83
2.160
133
3.160
183
4.160
33
1.160
84
2.180
134
3.180
184
4.180
34
1.180
85
2.200
135
3.200
185
4.200
35
1.200
86
2.220
136
3.220
186
4.220
36
1.220
87
2.240
137
3.240
187
4.240
37
1.240
88
2.260
138
3.260
188
4.260
38
1.260
89
2.280
139
3.280
189
4.280
39
1.280
90
2.300
140
3.300
190
4.300
40
1.300
91
2.320
141
3.320
191
4.320
41
1.320
92
2.340
142
3.340
192
4.340
42
1.340
93
2.360
143
3.360
193
4.360
43
1.360
94
2.380
144
3.380
194
4.380
44
1.380
95
2.400
145
3.400
195
4.400
45
1.400
96
2.420
146
3.420
196
4.420
46
1.420
97
2.440
147
3.440
197
4.440
47
1.440
98
2.460
148
3.460
198
4.460
48
1.460
99
2.480
149
3.480
199
4.480
49
1.480
100
2.500
150
3.500
200
4.500
50
1.500
