APPENDIX E — UPC OPEN CONTROLLER (cont)
NETWORK POINTS LIST (cont)
See legend on page 182.
BACNET
OBJECT ID
POINT NAME
READ
ONLY
UNITS
DEFAULT
VALUE
RANGE
BACNET
OBJECT NAME
UNIT
POINT
AV:1009
IAQ - PPM Indoor CO2
W
n/a
n/a
0-5000
iaq_1
IAQ
AV:1016
Static Pressure
R
in H2O
n/a
n/a
static_press_1
SP
AV:1022
HVAC Mode Numerical Form
R
n/a
n/a
n/a
hvac_mode_1
MODEHVAC
AV:1023
Current Running Capacity
R
%
n/a
n/a
cool_capacity_1
CAPTOTAL
AV:1024
Cooling Control Point
R
°F
n/a
n/a
cool_ctrl_point_1
COOLCPNT
AV:1025
Heating Control Point
R
°F
n/a
n/a
heat_ctrl_point_1
HEATCPNT
AV:1027
Leaving Air Temperature
R
°F
n/a
n/a
lvg_air_temperature_1
LAT
AV:1028
Economizer Act. Curr. Pos
R
%
n/a
n/a
econ_pos_1
ECONOPOS
AV:1030
Controlling Return Temp
W
°F
n/a
-40-240
ra_temp_1
RETURN_T
AV:1070
Building Pressure
R
in H2O
n/a
n/a
bldg_static_press_1
BP
AV:1500
Mixed Air Temperature
R
°F
n/a
n/a
ma_temp_1
MAT
AV:1600
Cir A Suction Pressure
R
psig
n/a
n/a
suction_press_a_1
SP_A
AV:1601
Cir A Discharge Pressure
R
psig
n/a
n/a
discharge_press_a_1
DP_A
AV:1602
Cir A Sat. Condensing Temperature
R
°F
n/a
n/a
sat_cond_temp_a_1
SCTA
AV:1603
Cir A Sat. Suction Temperature
R
°F
n/a
n/a
sat_suction_temp_a_1
SSTA
AV:1604
Cir B Suction Pressure
R
psig
n/a
n/a
suction_press_b_1
SP_B
AV:1605
Cir B Discharge Pressure
R
psig
n/a
n/a
discharge_press_b_1
DP_B
AV:1606
Cir B Sat. Condensing Temperature
R
°F
n/a
n/a
sat_cond_temp_b_1
SCTB
AV:1607
Cir B Sat. Suction Temperature
R
°F
n/a
n/a
sat_suction_temp_b_1
SSTB
AV:2003
Requested Heat Stage
R
n/a
n/a
n/a
heat_run_1
HT_STAGE
AV:2007
Controlling Space Temp
W
°F
n/a
-40-240
space_temp_1
SPACE_T
AV:2050
Supply Fan VFD Speed
R
%
n/a
n/a
sfvfdtst_1
SFAN_VFD
AV:2075
Exhaust Fan VFD Speed
R
%
n/a
n/a
ef_vfd_output_1
EFAN_VFD
AV:2901
User Defined Analog 1
n/a
n/a
n/a
n/a
user_analog_1_1
n/a
AV:2902
User Defined Analog 2
n/a
n/a
n/a
n/a
user_analog_2_1
n/a
AV:2903
User Defined Analog 3
n/a
n/a
n/a
n/a
user_analog_3_1
n/a
AV:2904
User Defined Analog 4
n/a
n/a
n/a
n/a
user_analog_4_1
n/a
AV:2905
User Defined Analog 5
n/a
n/a
n/a
n/a
user_analog_5_1
n/a
AV:3001
Cooling Occupied Setpoint
W
°F
75
40-99
occ_cl_stpt_1
OCSP
AV:3002
Heating Occupied Setpoint
W
°F
68
409-99
occ_ht_stpt_1
OHSP
AV:3003
Cooling Unoccupied Setpoint
W
°F
90
40-99
unocc_cl_stpt_1
UCSP
AV:3004
Heating Unoccupied Setpoint
W
°F
55
40-99
unocc_ht_stpt_1
UHSP
AV:3007
Supply Air Setpoint
W
°F
55
45-75
sa_temp_stpt_1
SASP
AV:3016
IAQ Demand Vent Min.Pos.
W
%
0
0-100
iaq_min_pos_1
IAQMINP
AV:3050
Static Pressure Setpoint
W
in H2O
1.5
0-5
sa_static_stpt_1
SPSP
AV:3070
Building Pressure Setp.
W
in H2O
0.05
-0.25-
0.25
bldg_press_stpt_1
BPSP
AV:4005
Economizer Min.Position
W
%
5
0-100
econ_min_1
ECONOMIN
AV:9008
High OAT Lockout Temp
W
°F
60
-40-120
econ_oat_lockout_1
OAT_LOCK
