140
APPENDIX A — LOCAL DISPLAY TABLES
MODE — RUN STATUS
ITEM EXPANSION RANGE UNITS CCN POINT WRITE STATUS PAGE NO.
VIEW AUTO VIEW OF RUN STATUS
 HVAC ascii string spelling out the hvac modes string 90,91
 OCC Occupied ? YES/NO OCCUPIED forcible 90,91
 MAT Mixed Air Temperature dF MAT 90,91
 EDT Evaporator Discharge Tmp dF EDT 90,91
 LAT Leaving Air Temperature dF LAT 90,91
 EC.C.P Economizer Control Point dF ECONCPNT 50,63,70,90,91
 ECN.P Economizer Act.Curr.Pos. 0-100 % ECONOPOS 90,91
 CL.C.P Cooling Control Point dF COOLCPNT 41,42,63,90,91
 C.CAP Current Running Capacity CAPTOTAL 90,91
 HT.C.P Heating Control Point dF HEATCPNT 53,90,91
 HT.ST Requested Heat Stage HT_STAGE 54-56,90,91
 H.MAX Maximum Heat Stages HTMAXSTG 54,90,91
ECON ECONOMIZER RUN STATUS
 ECN.P Economizer Act.Curr.Pos. 0-100 % ECONOPOS 50,64,91
 ECN.C Economizer Act.Cmd.Pos. 0-100 % ECONOCMD forcible 64,91
 ACTV Economizer Active ? YES/NO ECACTIVE 42,50,64,91
 DISA ECON DISABLING CONDITIONS 64,91
 DISA  UNAV Econ Act. Unavailable? YES/NO ECONUNAV 64,91
 DISA  R.EC.D Remote Econ. Disabled ? YES/NO ECONDISA 64,91
 DISA  DBC DBC - OAT Lockout? YES/NO DBC_STAT 64,91
 DISA  DEW DEW - OA Dewpt.Lockout? YES/NO DEW_STAT 64,91
 DISA  DDBC DDBD- OAT > RAT Lockout? YES/NO DDBCSTAT 64,91
 DISA  OAEC OAEC- OA Enth Lockout? YES/NO OAECSTAT 64,91
 DISA  DEC DEC - Diff.Enth.Lockout? YES/NO DEC_STAT 64,91
 DISA  EDT EDT Sensor Bad? YES/NO EDT_STAT 64,91
 DISA  OAT OAT Sensor Bad ? YES/NO OAT_STAT 64,91
 DISA  FORC Economizer Forced ? YES/NO ECONFORC 64,91
 DISA  SFON Supply Fan Not On 30s ? YES/NO SFONSTAT 64,91
 DISA  CLOF Cool Mode Not In Effect? YES/NO COOL_OFF 64,91
 DISA  OAQL OAQ Lockout in Effect ? YES/NO OAQLOCKD 64,91
 DISA  HELD Econ Recovery Hold Off? YES/NO ECONHELD 64,91
 DISA  DH.DS Dehumid. Disabled Econ? YES/NO DHDISABL 64,91
 O.AIR OUTSIDE AIR INFORMATION 64,91
 O.AIR  OAT Outside Air Temperature dF OAT forcible 64,91
 O.AIR  OA.RH Outside Air Rel. Humidity % OARH forcible 64,91
 O.AIR  OA.E Outside Air Enthalpy OAE 64,91
 O.AIR  OA.D.T OutsideAir Dewpoint Temp dF OADEWTMP 64,91
COOL COOLING INFORMATION
 C.CAP Current Running Capacity % CAPTOTAL 46,47,49,90,92
 CUR.S Current Cool Stage COOL_STG 46,47,63,90,92
 REQ.S Requested Cool Stage CL_STAGE 46,47,90,92
 MAX.S Maximum Cool Stages CLMAXSTG 46,47,90,92
 DEM.L Active Demand Limit DEM_LIM forcible 46-48,90,92
 SUMZ COOL CAP. STAGE CONTROL 46,47,90,92
 SUMZ  SMZ Capacity Load Factor % SMZ 46,47,90,92
 SUMZ  ADD.R Next Stage EDT Decrease ^F ADDRISE 43,46,47,90,92
 SUMZ  SUB.R Next Stage EDT Increase ^F SUBRISE 46,47,90,92
 SUMZ  R.PCT Rise Per Percent Capacity RISE_PCT 46,47,90,92
 SUMZ  Y.MIN Cap Deadband Subtracting Y_MINUS 46,47,90,92
 SUMZ  Y.PLU Cap Deadband Adding Y_PLUS 46,47,90,92
 SUMZ  Z.MIN Cap Threshold Subtracting Z_MINUS 46,47,91,92
 SUMZ  Z.PLU Cap Threshold Adding Z_PLUS 46,47,91,92
 SUMZ  H.TMP High Temp Cap Override HI_TEMP 46,47,91,92
 SUMZ  L.TMP Low Temp Cap Override LOW_TEMP 46,47,91,92
 SUMZ  PULL Pull Down Cap Override PULLDOWN 46,47,91,92
 SUMZ  SLOW Slow Change Cap Override SLO_CHNG 47,91,92
TRIP MODE TRIP HELPER
 UN.C.S Unoccup. Cool Mode Start UCCLSTRT 46,53,92
 UN.C.E Unoccup. Cool Mode End UCCL_END 46,53,92
 OC.C.S Occupied Cool Mode Start OCCLSTRT 46,53,92
 OC.C.E Occupied Cool Mode End OCCL_END 46,53,92
 TEMP Ctl.Temp RAT,SPT or Zone CTRLTEMP 46,53,92
 OC.H.E Occupied Heat Mode End OCHT_END 46,53,92
 OC.H.S Occupied Heat Mode Start OCHTSTRT 46,53,92
 UN.H.E Unoccup. Heat Mode End UCHT_END 46,53,92
 UN.H.S Unoccup. Heat Mode Start UCHTSTRT 46,53,92
 HVAC ascii string spelling out the hvac modes string 46,53,92
LINK CCN - LINKAGE
 MODE Linkage Active - CCN ON/OFF MODELINK 92
 L.Z.T Linkage Zone Control Tmp dF LZT 92
 L.C.SP Linkage Curr. Cool Setpt dF LCSP 92
 L.H.SP Linkage Curr. Heat Setpt dF LHSP 92
HRS COMPRESSOR RUN HOURS
 HR.A1 Compressor A1 Run Hours 0-999999 HRS HR_A1 config 92
 HR.A2 Compressor A2 Run Hours 0-999999 HRS HR_A2 config 92
 HR.B1 Compressor B1 Run Hours 0-999999 HRS HR_B1 config 92
 HR.B2 Compressor B2 Run Hours 0-999999 HRS HR_B2 config 92
STRT COMPRESSOR STARTS
 ST.A1 Compressor A1 Starts 0-999999 CY_A1 config 92
 ST.A2 Compressor A2 Starts 0-999999 CY_A2 config 92
 ST.B1 Compressor B1 Starts 0-999999 CY_B1 config 92
 ST.B2 Compressor B2 Starts 0-999999 CY_B2 config 92
