Carrier WEATHERMAKER 48/50AJ - Manual (Page 185)

Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Catalog No. 04-53480077-01 Printed in U.S.A. Form 48/50A-9T Pg CL-1 6-10 Replaces: 48/50A-7T
CONTROLS SET POINT AND CONFIGURATION LOG
MODEL NUMBER: Software Version
SERIAL NUMBER: MBB CESR131343--
DATE: RCB CESR131249--
TECHNICIAN: ECB CESR131249--
NAVI CESR131227--
SCB CESR131226--
CEM CESR131174--
MARQ CESR131171--
ITEM EXPANSION RANGE DEFAULT ENTRY
UNIT UNIT CONFIGURATION

C.TYP Machine Control Type 1 - 6 (multi-text strings) 4

CV.FN Fan Mode (0=Auto, 1=Cont) 0 - 1 (multi-text strings) 1

RM.CF Remote Switch Config 0 - 3 (multi-text strings) 0

CEM CEM Module Installed Yes/No No

TCS.C Temp.Cmp.Strt.Cool Factr 0 - 60 min 0

TCS.H Temp.Cmp.Strt.Heat Factr 0 - 60 min 0

SFS.S Fan Fail Shuts Down Unit Yes/No No

SFS.M Fan Stat Monitoring Type 0 - 2 (multi-text strings) 0

VAV.S VAV Unocc.Fan Retry Time 0 - 720 min 50

SIZE Unit Size (20-60) 20 - 60 20

DP.XR Disch.Press. Transducers Yes/No No

SP.XR Suct. Pres. Trans. Type 0 -1 (multi-text strings) 0

RFG.T Refrig: 0=R22 1=R410A 0 -1 (multi-text strings) 1

CND.T Cnd HX Typ:0=RTPF 1=MCHX 0 -1 (multi-text strings) 0

MAT.S MAT Calc Config 0 - 2 (multi-text strings) 1

MAT.R Reset MAT Table Entries? Yes/No No

MAT.D MAT Outside Air Default 0-100% 20

ALTI Altitude……..in feet: 0 - 60000 0

DLAY Startup Delay Time 0 - 900 sec 0

STAT TSTAT_Both Heat and Cool Yes/No No

AUX.R Auxiliary Relay Config 0 - 3 0

SENS INPUT SENSOR CONFIG

SENS

SPT.S Space Temp Sensor Enable/Disable Disable

SENS

SP.O.S Space Temp Offset Sensor Enable/Disable Disable

SENS

SP.O.R Space Temp Offset Range 1 - 10 5

SENS

RRH.S Return Air RH Sensor Enable/Disable Disable

SENS

FLT.S Filter Stat.Sw.Enabled ? Enable/Disable Disable
COOL COOLING CONFIGURATION

Z.GN Capacity Threshold Adjst –10

- 10 1

MC.LO Compressor Lockout Temp –20 - 55 dF 40

C.FOD Fan-Off Delay, Mech Cool 0 - 600 sec 60

MLV Min. Load Valve? (HGBP) Yes/No No

M.M. Motor Master Control Yes/No No

HPSP Head Pressure Setpoint 80 - 150 dF 113

A1.EN Enable Compressor A1 Enable/Disable Enable

A2.EN Enable Compressor A2 Enable/Disable Enable

B1.EN Enable Compressor B1 Enable/Disable Enable

B2.EN Enable Compressor B2 Enable/Disable Enable

CS.A1 CSB A1 Feedback Alarm Enable/Disable Enable

CS.A2 CSB A2 Feedback Alarm Enable/Disable Enable

CS.B1 CSB B1 Feedback Alarm Enable/Disable Enable

CS.B2 CSB B2 Feedback Alarm Enable/Disable Enable

REV.R Rev Rotation Verified ? Yes/No No

H.SST Hi SST Alert DelayTime 5 - 30 min 10
EDT.R EVAP.DISCHRGE TEMP RESET

RS.CF EDT Reset Configuration 0 - 3 (multi-text strings) 0

RTIO Reset Ratio 0 - 10 2

LIMT Reset Limit 0 - 20 ^F 10

RES.S EDT 4-20 ma Reset Input Enable/Disable Disable
