APPENDIX A — LOCAL DISPLAY TABLES (cont)
MODE — PRESSURES
MODE — SET POINTS
MODE — INPUTS
*The display text changes depending on the remote switch configuration (Configuration
UNIT
RM.CF). If RM.CF is set to 0 (No Remote
Switch), then the display text will be “On” or “Off.” If RM.CF is set to 1 (Occupied/Unoccupied Switch), then the display text will be “Occupied” or
“Unoccupied.” If RM.CF is set to 2 (Start/Stop), then the display text will be “Stop” or “Start.” If RM.CF is set to 3 (Override Switch), then the display
text will be “No Override” or “Override.”
ITEM
EXPANSION
RANGE
UNITS
CCN POINT
WRITE STATUS
AIR.P
AIR PRESSURES
SP
Static Pressure
"H2O
SP
BP
Building Pressure
"H2O
BP
REF.P
REFRIGERANT PRESSURES
DP.A
Cir A Discharge Pressure
PSIG
DP_A
SP.A
Cir A Suction Pressure
PSIG
SP_A
DP.B
Cir B Discharge Pressure
PSIG
DP_B
SP.B
Cir B Suction Pressure
PSIG
SP_B
ITEM
DESCRIPTION
RANGE
UNITS
CCN POINT
DEFAULT
OHSP
Occupied Heat Setpoint
40-99
dF
OHSP
68
OCSP
Occupied Cool Setpoint
40-99
dF
OCSP
75
UHSP
Unoccupied Heat Setpoint
40-99
dF
UHSP
55
UCSP
Unoccupied Cool Setpoint
40-99
dF
UCSP
90
GAP
Heat-Cool Setpoint Gap
2-10
^F
HCSP_GAP
5
V.C.ON
VAV Occ. Cool On Delta
0-25
^F
VAVOCON
3.5
V.C.OF
VAV Occ. Cool Off Delta
1-25
^F
VAVOCOFF
2
SASP
Supply Air Setpoint
45-75
dF
SASP
55
SA.HI
Supply Air Setpoint Hi
45-75
dF
SASP_HI
55
SA.LO
Supply Air Setpoint Lo
45-75
dF
SASP_LO
60
SA.HT
Heating Supply Air Setpt
80-120
dF
SASPHEAT
85
T.PRG
Tempering Purge SASP
–20-80
dF
TEMPPURG
50
T.CL
Tempering in Cool SASP
5-75
dF
TEMPCOOL
5
T.V.OC
Tempering Vent Occ SASP
–20-80
dF
TEMPVOCC
65
T.V.UN
Tempering Vent Unocc. SASP
–20-80
dF
TEMPVUNC
50
ITEM
EXPANSION
RANGE
UNITS
CCN POINT
WRITE STATUS
GEN.I
GENERAL INPUTS
FLT.S
Filter Status Input
DRTY/CLN
FLTS
forcible
G.FAN
Fan Request From IGC
ON/OFF
IGCFAN
REMT
Remote Input State
*
RMTIN
forcible
E.SW
Economizer Control Input
YES/NO
ECOSW
forcible
E.ENA
Remote Economizer Enable
YES/NO
ECONENBL
forcible
E.OVR
Econo Position Override
YES/NO
ECOORIDE
forcible
S.FN.S
Supply Fan Status Switch
ON/OFF
SFS
forcible
DL.S1
Demand Limit Switch 1
ON/OFF
DMD_SW1
forcible
DL.S2
Demand Limit Switch 2
ON/OFF
DMD_SW2
forcible
DH.IN
Dehumidify Switch Input
ON/OFF
DHDISCIN
forcible
FD.BK
COMPRESSOR FEEDBACK
CS.A1
Compressor A1 Feedback
ON/OFF
CSB_A1
CS.A2
Compressor A2 Feedback
ON/OFF
CSB_A2
CS.B1
Compressor B1 Feedback
ON/OFF
CSB_B1
CS.B2
Compressor B2 Feedback
ON/OFF
CSB_B2
STAT
THERMOSTAT INPUTS
G
Thermostat G Input
ON/OFF
G
forcible
W1
Thermostat W1 Input
ON/OFF
W1
forcible
W2
Thermostat W2 Input
ON/OFF
W2
forcible
Y1
Thermostat Y1 Input
ON/OFF
Y1
forcible
Y2
Thermostat Y2 Input
ON/OFF
Y2
forcible
FIRE
FIRE-SMOKE INPUTS
FSD
Fire Shutdown Input
ALARM/NORMAL
FSD
forcible
PRES
Pressurization Input
ALARM/NORMAL
PRES
forcible
EVAC
Evacuation Input
ALARM/NORMAL
EVAC
forcible
PURG
Smoke Purge Input
ALARM/NORMAL
PURG
forcible
REL.H
RELATIVE HUMIDITY
OA.RH
Outside Air Rel. Humidity
%
OARH
forcible
OA.EN
Outdoor Air Enthalpy
OAE
OA.DP
OutsideAir Dewpoint Temp
dF
OADEWTMP
RA.RH
Return Air Rel. Humidity
%
RARH
forcible
RA.EN
Return Air Enthalpy
RAE
AIR.Q
AIR QUALITY SENSORS
IAQ.I
IAQ - Discrete Input
HIGH/LOW
IAQIN
forcible
IAQ
IAQ - PPM Return CO2
IAQ
forcible
OAQ
OAQ - PPM Return CO2
OAQ
forcible
DAQ
Diff.Air Quality in PPM
DAQ
IQ.P.O
IAQ Min.Pos. Override
%
IAQMINOV
forcible
RSET
RESET INPUTS
SA.S.R
Supply Air Setpnt. Reset
^F
SASPRSET
forcible
SP.RS
Static Pressure Reset
SPRESET
forcible
