159
APPENDIX B — CCN TABLES (cont)
MAINTENANCE DISPLAY TABLES (cont)
TABLE DISPLAY NAME RANGE UNITS POINT NAME WRITE STATUS
PRESBLDG
Building Pressure "H2O BP
Econo Damper Current Pos % ECONOPOS
Power Exhaust Stage A PE_A
Power Exhaust Stage B PE_B
Power Exhaust Stage C PE_C
BP Load Factor BPSMZ
BP Rise Per Stage BPRISE
BP PID/Integral Term BPINT config
BP PID Threshold BPZ config
BP Deadband BPY config
Building Pressure Error BPERROR config
Rate of Chng of BPERROR BPRATE config
High BP Override BPHPOVRD config
Low BP Override BPLPOVRD config
PRESDUCT
Static Pressure "H2O SP
Supply Fan VFD Speed % SFAN_VFD
Static Pressure Setpoint "H2O SPSP config
Static Pressure Reset SPRESET forcible
STAGEGAS
Heating Mode………..:
Requested Heat Stage
HT_STAGE
Heating Control Point HEATCPNT
Staged Gas LAT Sum dF LAT_SGAS
Staged Gas LAT 1 dF LAT1SGAS
Staged Gas LAT 2 dF LAT2SGAS
Staged Gas LAT 3 dF LAT3SGAS
Staged Gas Limit Sw.Temp dF LIMSWTMP
Heat PID Timer sec HTSGTIMR
Staged Gas Capacity Calc % HTSGCALC
Current Running Capacity % HTSG_CAP
Proportional Cap. Change HTSG_P
Derivative Cap. Change HTSG_D
Maximum Heat Stages HTMAXSTG
Hi Limit Switch Tmp Mode LIMTMODE
LAT Cutoff Mode LATCMODE
Capacity Clamp Mode CAPMODE
STRTHOUR
Compressor A1 Run Hours hours HR_A1 config
Compressor A2 Run Hours hours HR_A2 config
Compressor B1 Run Hours hours HR_B1 config
Compressor B2 Run Hours hours HR_B2 config
Compressor A1 Starts CY_A1 config
Compressor A2 Starts CY_A2 config
Compressor B1 Starts CY_B1 config
Compressor B2 Starts CY_B2 config
SUMZ
Cooling Control Point dF COOLCPNT
Mixed Air Temperature dF MAT
Evaporator Discharge Tmp dF EDT
Return Air Temperature dF RAT
Outside Air Temperature dF OAT
Econo Damper Current Pos % ECONOPOS
Capacity Threshold Adjst Z_GAIN
Capacity Load Factor SMZ
Next Stage EDT Decrease ADDRISE
Next Stage EDT Increase SUBRISE
Rise Per Percent Capacity RISE_PCT
Cap Deadband Subtracting Y_MINUS
Cap Deadband Adding Y_PLUS
Cap Threshold Subtracting Z_MINUS
Cap Threshold Adding Z_PLUS
High Temp Cap Override On/Off HI_TEMP
Low Temp Cap Override On/Off LOW_TEMP
Pull Down Cap Override On/Off PULLDOWN
Slow Change Cap Override On/Off SLO_CHNG
SYSTEM
Reset All Current Alarms Yes/No ALRESET config
Reset the Device Yes/No RESETDEV config
Local Machine Disable Yes/No UNITSTOP config
Soft Stop Request Yes/No SOFTSTOP forcible
Emergency Stop Enable/Disable EMSTOP forcible
CEM AN1 10K temp J5,1-2 -40 - 240 dF CEM10K1 forcible
CEM AN2 10K temp J5,3-4 -40 - 240 dF CEM10K2 forcible
CEM AN3 10K temp J5,5-6 -40 - 240 dF CEM10K3 forcible
CEM AN4 10K temp J5,7-8 -40 - 240 dF CEM10K4 forcible
CEM AN1 4-20 ma J5,1-2 0-20 ma CEM4201 forcible
CEM AN2 4-20 ma J5,3-4 0-20 ma CEM4202 forcible
CEM AN3 4-20 ma J5,5-6 0-20 ma CEM4203 forcible
CEM AN4 4-20 ma J5,7-8 0-20 ma CEM4204 forcible
