Carrier WEATHERMAKER 48/50AJ User Manual
Page 187
CL-3
ITEM
EXPANSION
RANGE
DEFAULT
ENTRY
BP
BUILDING PRESS. CONFIG
BP.CF
Building Press. Config
0-2
0
BP.RT
Bldg.Pres.PID Run Rate
5-120 sec
10
BP.P
Bldg. Press. Prop. Gain
0-5
0.5
BP.I
Bldg.Press.Integ.Gain
0-2
0.5
BP.D
Bldg.Press.Deriv.Gain
0-5
0.3
BP.SO
BP Setpoint Offset
0.0 - 0.5 “H2O
0.05
BP.MN
BP VFD Minimum Speed
0-100%
10
BP.MX
BP VFD Maximum Speed
0-100%
100
BP.FS
VFD/Act. Fire Speed/Pos.
0-100%
100
BP.MT
Power Exhaust Motors
1-2
1
BP.S
Building Pressure Sensor
Enable/Dsable
Dsable
BP.R
Bldg Press (+/-) Range
0 - 1.00 “H2O
0.25
BP.SP
Building Pressure Setp.
–0.25
0.25 "H2O
0.05
BP.P1
Power Exhaust On Setp.1
0 - 100 %
35
BP.P2
Power Exhaust On Setp.2
0 - 100 %
75
B.CFG
BP ALGORITHM CONFIGS
B.CFG
BP.SL
Modulating PE Alg. Slct.
1-3
1
B.CFG
BP.TM
BP PID Evaluation Time
0 - 10 min
1
B.CFG
BP.ZG
BP Threshold Adjustment
0.1 - 10.0 “H2O
1
B.CFG
BP.HP
High BP Level
0 - 1.000 “H2O
0.05
B.CFG
BP.LP
Low BP Level
0 - 1.000 “H2O
0.04
D.LV.T
COOL/HEAT SETPT. OFFSETS
L.H.ON
Dmd Level Lo Heat On
–1 - 2 ^F
1.5
H.H.ON
Dmd Level(+) Hi Heat On
0.5 - 20.0 ^F
0.5
L.H.OF
Dmd Level(-) Lo Heat Off
0.5 - 2 ^F
1
L.C.ON
Dmd Level Lo Cool On
–1 - 2 ^F
1.5
H.C.ON
Dmd Level(+) Hi Cool On
0.5 - 20.0 ^F
0.5
L.C.OF
Dmd Level(-) Lo Cool Off
0.5 - 2 ^F
1
C.T.LV
Cool Trend Demand Level
0.1 - 5 ^F
0.1
H.T.LV
Heat Trend Demand Level
0.1 - 5 ^F
0.1
C.T.TM
Cool Trend Time
30 - 600 sec
120
H.T.TM
Heat Trend Time
30 - 600 sec
120
DMD.L
DEMAND LIMIT CONFIG.
DM.L.S
Demand Limit Select
0 - 3 (multi-text strings)
0
D.L.20
Demand Limit at 20 ma
0 - 100 %
100
SH.NM
Loadshed Group Number
0 - 99
0
SH.DL
Loadshed Demand Delta
0 - 60 %
0
SH.TM
Maximum Loadshed Time
0 - 120 min
60
D.L.S1
Demand Limit Sw.1 Setpt.
0 - 100 %
80
D.L.S2
Demand Limit Sw.2 Setpt.
0 - 100 %
50
IAQ
INDOOR AIR QUALITY CFG.
DCV.C
DCV ECONOMIZER SETPOINTS
DCV.C
EC.MN
Economizer Min.Position
0 - 100 %
5
DCV.C
IAQ.M
IAQ Demand Vent Min.Pos.
0 - 100 %
0
AQ.CF
AIR QUALITY CONFIGS
AQ.CF
IQ.A.C
IAQ Analog Sensor Config
0 - 4 (multi-text strings)
0
AQ.CF
IQ.A.F
IAQ 4-20 ma Fan Config
0 - 2 (multi-text strings)
0
AQ.CF
IQ.I.C
IAQ Discrete Input Config
0 - 2 (multi-text strings)
0
AQ.CF
IQ.I.F
IAQ Disc.In. Fan Config
0 - 2 (multi-text strings)
0
AQ.CF
OQ.A.C
OAQ 4-20ma Sensor Config
0 - 2 (multi-text strings)
0
AQ.SP
AIR QUALITY SETPOINTS
AQ.SP
IQ.O.P
IAQ Econ Override Pos.
0 - 100 %
100
AQ.SP
DAQ.L
Diff.Air Quality LoLimit
0 - 1000
100
AQ.SP
DAQ.H
Diff.Air Quality HiLimit
100 - 2000
700
AQ.SP
D.F.OF
DAQ PPM Fan Off Setpoint
0 - 2000
200
AQ.SP
D.F.ON
DAQ PPM Fan On Setpoint
0 - 2000
400
AQ.SP
IAQ.R
Diff. AQ Responsiveness
–5 - 5
0
AQ.SP
OAQ.L
OAQ Lockout Value
0 - 2000
0
AQ.SP
OAQ.U
User Determined OAQ
0 - 5000
400
AQ.S.R
AIR QUALITY SENSOR RANGE
