APPENDIX A — LOCAL DISPLAY TABLES (cont)
MODE — RUN STATUS (cont)
MODE — SERVICE TEST
MODE — TEMPERATURES
ITEM EXPANSION RANGE UNITS CCN POINT WRITE STATUS PAGE NO.
TMGD TIMEGUARDS
 TG.A1 Compressor A1 Timeguard CMPA1_TG 93
 TG.A2 Compressor A2 Timeguard CMPA2_TG 93
 TG.B1 Compressor B1 Timeguard CMPB1_TG 93
 TG.B2 Compressor B2 Timeguard CMPB2_TG 93
 TG.H1 Heat Relay 1 Timeguard HS1_TG 93
 TG.H2 Heat Relay 2 Timeguard HS2_TG 93
 TG.H3 Heat Relay 3 Timeguard HS3_TG 93
 TG.H4 Heat Relay 4 Timeguard HS4_TG 93
 TG.H5 Heat Relay 5 Timeguard HS5_TG 93
 TG.H6 Heat Relay 6 Timeguard HS6_TG 93
VERS SOFTWARE VERSION NUMBERS
 MBB CESR131343-xx-xx string 93
 ECB1 CESR131249-xx-xx string 93
 ECB2 CESR131249-xx-xx string 93
 SCB CESR131226-xx-xx string 93
 CEM CESR131174-xx-xx string 93
 MARQ CESR131171-xx-xx string 93
 NAVI CESR130227-xx-xx string 93
ITEM EXPANSION RANGE UNITS CCN POINT WRITE STATUS PAGE NO.
TEST Service Test Mode ON/OFF MAN_CTRL
STOP Local Machine Disable YES/NO UNITSTOP config 27,29,30
S.STP Soft Stop Request YES/NO SOFTSTOP forcible 29,30
FAN.F Supply Fan Request YES/NO SFANFORC forcible 29,30
F.4.CH 4 in. Filter Change Mode YES/NO FILT4CHG 29,30
INDP TEST INDEPENDENT OUTPUTS
 ECN.C Economizer Act.Cmd.Pos. ECONCTST 30
 E.PWR Economizer Power Test ECONPTST 30
 E.CAL Calibrate the Economizer? ECON_CAL 30
 PE.A Power Exhaust Relay A PE_A_TST 30
 PE.B Power Exhaust Relay B PE_B_TST 30
 PE.C Power Exhaust Relay C PE_C_TST 30
 H.I.R Heat Interlock Relay ON/OFF HIR_TST 30
 ALRM Remote Alarm/Aux Relay ON/OFF ALRM_TST 30
FANS TEST FANS
 S.FAN Supply Fan Relay ON/OFF SFAN_TST 30
 S.VFD Supply Fan VFD Speed 0-100 % SGVFDTST 30
 CD.F.A Condenser Fan Circuit A ON/OFF CNDA_TST 30
 CD.F.B Condenser Fan Circuit B ON/OFF CNDB_TST 30
COOL TEST COOLING
 A1 Compressor A1 Relay ON/OFF CMPA1TST 30
 A2 Compressor A2 Relay ON/OFF CMPA2TST 30
 MLV Min. Load Valve (HGBP) ON/OFF MLV_TST 30
 B1 Compressor B1 Relay ON/OFF CMPB1TST 30
 B2 Compressor B2 Relay ON/OFF CMPB2TST 30
HEAT TEST HEATING
 HT.ST Requested Heat Stage 0-MAX HTST_TST 30
 HT.1 Heat Relay 1 ON/OFF HS1_TST 30
 HT.2 Heat Relay 2 ON/OFF HS2_TST 30
 HT.3 Relay 3 W1 Gas Valve 2 ON/OFF HS3_TST 30
 HT.4 Relay 4 W2 Gas Valve 2 ON/OFF HS4_TST 30
 HT.5 Relay 5 W1 Gas Valve 3 ON/OFF HS5_TST 30
 HT.6 Relay 6 W2 Gas Valve 3 ON/OFF HS6_TST 30
ITEM EXPANSION RANGE UNITS CCN POINT WRITE STATUS
AIR.T AIR TEMPERATURES
 CTRL CONTROL TEMPS
 CTRL  EDT Evaporator Discharge Tmp dF EDT
 CTRL  LAT Leaving Air Temperature dF LAT
 CTRL  MAT Mixed Air Temperature dF MAT
 CTRL  R.TMP Controlling Return Temp dF RETURN_T forcible
 CTRL  S.TMP Controlling Space Temp dF SPACE_T forcible
 SAT Air Tmp Lvg Supply Fan dF SAT
 OAT Outside Air Temperature –40 - 240 dF OAT forcible
 RAT Return Air Temperature dF RAT forcible
 SPT Space Temperature –40 - 240 dF SPT forcible
 SPTO Space Temperature Offset ^F SPTO forcible
 S.G.LS Staged Gas LAT Sum dF LAT_SGAS
 S.G.L1 Staged Gas LAT 1 dF LAT1SGAS
 S.G.L2 Staged Gas LAT 2 dF LAT2SGAS
 S.G.L3 Staged Gas LAT 3 dF LAT3SGAS
 S.G.LM Staged Gas Limit Sw.Temp dF LIMSWTMP
REF.T REFRIGERANT TEMPERATURES
 SCT.A Cir A Sat.Condensing Tmp dF SCTA
 SST.A Cir A Sat.Suction Temp. dF SSTA
 SCT.B Cir B Sat.Condensing Tmp dF SCTB
 SST.B Cir B Sat.Suction Temp. dF SSTB
