10
Table 7 — Fan Performance — 48AJ,AK,A2,A3040 Units
Table 8 — Fan Performance — 48AJ,AK041 Units
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 2.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
8,000 502 2.90 550 3.30 596 3.71 639 4.12 680 4.54 720 4.97 759 5.40 796 5.85 832 6.31 867 6.77
9,000 552 3.81 595 4.24 637 4.67 677 5.11 715 5.55 752 6.00 788 6.45 823 6.92 857 7.39 890 7.87
10,000 602 4.89 642 5.34 680 5.80 717 6.26 752 6.73 787 7.20 821 7.67 854 8.16 886 8.64 917 9.14
11,000 653 6.15 689 6.62 725 7.11 759 7.59 792 8.08 825 8.58 856 9.07 887 9.57 918 10.08 947 10.59
12,000 704 7.60 738 8.09 771 8.60 803 9.11 834 9.63 865 10.14 895 10.66 924 11.18 952 11.71 980 12.24
13,000 756 9.24 788 9.76 818 10.29 848 10.83 878 11.36 906 11.90 935 12.44 962 12.99 989 13.53 1016 14.08
14,000 808 11.10 838 11.64 867 12.19 895 12.74 922 13.30 950 13.87 976 14.43 1002 15.00 1028 15.57 1053 16.14
15,000 861 13.18 888 13.74 915 14.31 942 14.88 968 15.46 994 16.05 1019 16.63 1044 17.22 1068 17.81 1093 18.40
16,000 914 15.49 940 16.06 965 16.65 990 17.24 1015 17.85 1039 18.45 1063 19.06 1087 19.67 1110 20.28 1133 20.89
17,000 967 18.03 991 18.62 1015 19.23 1039 19.85 1062 20.47 1086 21.09 1109 21.72 1131 22.35 1153 22.98 1175 23.61
18,000 1020 20.82 1043 21.43 1066 22.06 1088 22.69 1111 23.33 1133 23.97 1155 24.62 1176 25.27 1197 25.92 1219 26.58
19,000 1073 23.87 1095 24.50 1117 25.14 1138 25.79 1159 26.44 1180 27.11 1201 27.77 1222 28.45 1242 29.12 — —
20,000 1127 27.18 1147 27.82 1168 28.48 1188 29.15 — — — — — — — — — — — —
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
2.2 2.4 2.6 2.8 3.0 3.2 3.4 3.6 3.8 4.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
8,000 901 7.24 933 7.72 965 8.20 995 8.69 1024 9.19 1053 9.69 1081 10.19 1108 10.70 1134 11.21 1159 11.73
9,000 923 8.35 954 8.85 985 9.35 1014 9.86 1043 10.37 1072 10.89 1099 11.41 1126 11.94 1152 12.47 1177 13.00
10,000 948 9.64 978 10.15 1007 10.66 1036 11.19 1064 11.71 1092 12.25 1119 12.78 1145 13.33 1171 13.88 1196 14.43
11,000 976 11.11 1005 11.63 1033 12.16 1061 12.70 1088 13.24 1114 13.79 1140 14.34 1166 14.90 1191 15.46 1216 16.03
12,000 1008 12.77 1035 13.31 1062 13.86 1088 14.41 1114 14.97 1139 15.53 1164 16.09 1189 16.67 1213 17.24 1237 17.83
13,000 1042 14.64 1068 15.19 1093 15.76 1118 16.32 1143 16.89 1167 17.47 1191 18.05 1215 18.64 1238 19.23 1262 19.82
14,000 1078 16.71 1103 17.28 1127 17.86 1151 18.45 1174 19.03 1198 19.63 1221 20.22 1244 20.82 1266 21.43 1288 22.04
15,000 1116 19.00 1140 19.59 1163 20.19 1186 20.79 1208 21.40 1230 22.00 1253 22.62 1274 23.23 1296 23.85 — —
16,000 1156 21.51 1178 22.12 1200 22.74 1222 23.36 1244 23.98 1265 24.61 1286 25.24 — — — — — —
17,000 1197 24.25 1218 24.89 1240 25.52 1261 26.17 1281 26.81 — — — — — — — — — —
18,000 1239 27.24 1260 27.89 1280 28.55 — — — — — — — — — — — — — —
19,000 — — — — — — — — — — — — — — — — — — — —
20,000 — — — — — — — — — — — — — — — — — — — —
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
8,000 502 2.90 550 3.30 596 3.71 639 4.12 680 4.54
9,000 552 3.81 595 4.24 637 4.67 677 5.11 715 5.55
10,000 602 4.89 642 5.34 680 5.80 717 6.26 752 6.73
11,000 653 6.15 689 6.62 725 7.11 759 7.59 792 8.08
12,000 704 7.60 738 8.09 771 8.60 803 9.11 834 9.63
13,000 756 9.24 788 9.76 818 10.29 848 10.83 878 11.36
14,000 808 11.10 838 11.64 867 12.19 895 12.74 922 13.30
15,000 861 13.18 888 13.74 915 14.31 942 14.88 968 15.46
16,000 914 15.49 940 16.06 965 16.65 990 17.24 1015 17.85
17,000 967 18.03 991 18.62 1015 19.23 1039 19.85 1062 20.47
18,000 1020 20.82 1043 21.43 1066 22.06 1088 22.69 1111 23.33
19,000 1073 23.87 1095 24.50 1117 25.14 1138 25.79 1159 26.44
20,000 1127 27.18 1147 27.82 1168 28.48 1188 29.15 — —
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
8,000 720 4.97 759 5.40 796 5.85 832 6.31 867 6.77
9,000 752 6.00 788 6.45 823 6.92 857 7.39 890 7.87
10,000 787 7.20 821 7.67 854 8.16 886 8.64 917 9.14
11,000 825 8.58 856 9.07 887 9.57 918 10.08 947 10.59
12,000 865 10.14 895 10.66 924 11.18 952 11.71 980 12.24
13,000 906 11.90 935 12.44 962 12.99 989 13.53 1016 14.08
14,000 950 13.87 976 14.43 1002 15.00 1028 15.57 1053 16.14
15,000 994 16.05 1019 16.63 1044 17.22 1068 17.81 1093 18.40
16,000 1039 18.45 1063 19.06 1087 19.67 1110 20.28 1133 20.89
17,000 1086 21.09 1109 21.72 1131 22.35 1153 22.98 1175 23.61
18,000 1133 23.97 1155 24.62 1176 25.27 1197 25.92 1219 26.58
19,000 1180 27.11 1201 27.77 1222 28.45 1242 29.12 — —
20,000 — — — — — — — — — —
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
2.2 2.4 2.6 2.8 3.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
8,000 901 7.24 933 7.72 965 8.20 995 8.69 1024 9.19
9,000 923 8.35 954 8.85 985 9.35 1014 9.86 1043 10.37
10,000 948 9.64 978 10.15 1007 10.66 1036 11.19 1064 11.71
11,000 976 11.11 1005 11.63 1033 12.16 1061 12.70 1088 13.24
12,000 1008 12.77 1035 13.31 1062 13.86 1088 14.41 1114 14.97
13,000 1042 14.64 1068 15.19 1093 15.76 1118 16.32 1143 16.89
14,000 1078 16.71 1103 17.28 1127 17.86 1151 18.45 1174 19.03
15,000 1116 19.00 1140 19.59 1163 20.19 1186 20.79 1208 21.40
16,000 1156 21.51 1178 22.12 1200 22.74 1222 23.36 1244 23.98
17,000 1197 24.25 1218 24.89 1240 25.52 1261 26.17 1281 26.81
18,000 1239 27.24 1260 27.89 1280 28.55 — — — —
19,000 — — — — — — — — — —
20,000 — — — — — — — — — —
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
3.2 3.4 3.6 3.8 4.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
8,000 1053 9.69 1081 10.19 1108 10.70 1134 11.21 1159 11.73
9,000 1072 10.89 1099 11.41 1126 11.94 1152 12.47 1177 13.00
10,000 1092 12.25 1119 12.78 1145 13.33 1171 13.88 1196 14.43
11,000 1114 13.79 1140 14.34 1166 14.90 1191 15.46 1216 16.03
12,000 1139 15.53 1164 16.09 1189 16.67 1213 17.24 1237 17.83
13,000 1167 17.47 1191 18.05 1215 18.64 1238 19.23 1262 19.82
14,000 1198 19.63 1221 20.22 1244 20.82 1266 21.43 1288 22.04
15,000 1230 22.00 1253 22.62 1274 23.23 1296 23.85 — —
16,000 1265 24.61 1286 25.24 — — — — — —
17,000 — — — — — — — — — —
18,000 — — — — — — — — — —
19,000 — — — — — — — — — —
20,000 — — — — — — — — — —
