153
APPENDIX B — CCN TABLES (cont)
SERVICE-CONFIG TABLES (cont)
TABLE NAME RANGE UNITS POINT NAME DEFAULT
COOL
Capacity Threshold Adjust –10 -> 10 Z_GAIN 1
Compressor Lockout Temp –20 -> 55 dF OATLCOMP 40
Fan-off Delay, Mech Cool 0-600 sec COOL_FOD 60
Minimum Load Valve? Yes/No MLV_SEL No
Motor Master Control ? Yes/No MOTRMAST No
Head Pressure Setpoint 80-150 dF HPSP 110
Enable Compressor A1 Enable/Disable CMPA1ENA Enable
Enable Compressor A2 Enable/Disable CMPA2ENA Enable
Enable Compressor B1 Enable/Disable CMPB1ENA Enable
Enable Compressor B2 Enable/Disable CMPB2ENA Enable
CSB A1 Feedback Alarm Enable/Disable CSB_A1EN Enable
CSB A2 Feedback Alarm Enable/Disable CSB_A2EN Enable
CSB B1 Feedback Alarm Enable/Disable CSB_B1EN Enable
CSB B2 Feedback Alarm Enable/Disable CSB_B2EN Enable
Rev. Rotation Verified ? Yes/No REVR_VER No
Hi SST Alert Delay Time 5-30 min HSSTTIME 10
DEHU
Dehumidification Config 0-2 DHSELECT 0
Dehumidification Sensor 1-2 DHSENSOR 1
Econ disable in DH mode? Yes/No DHECONEN No
Vent Reheat Setpt Select 0-1 DHVHTCFG 0
Vent Reheat RAT offset 0-8 ^F DHVRAOFF 0
Vent Reheat Setpoint 55-95 dF DHVHT_SP 70
Dehumidify Cool Setpoint 40-55 dF DHCOOLSP 45
Dehumidify RH Setpoint 10-90 % DHRELHSP 55
DISP
Metric Display Off/On DISPUNIT Off
Language Selection 0-1 LANGUAGE 0
Password Enable Enable/Disable PASS_EBL Enable
Service Password 0000-9999 PASSWORD 1111
Contrast Adjustment –255 - 255 CNTR_ADJ 0
Brightness Adjustment –255 - 255 BRTS_ADJ 0
DLVT
Dmd Level Lo Heat On –1 - 2 ^F DMDLHON 1.5
Dmd Level(+) Hi Heat On 0.5 - 20.0 ^F DMDHHON 0.5
Dmd Level(-) Lo Heat Off 0.5 - 2 ^F DMDLHOFF 1
Dmd Level Lo Cool On –1 - 2 ^F DMDLCON 1.5
Dmd Level(+) Hi Cool On 0.5 - 20.0 ^F DMDHCON 0.5
Dmd Level(-) Lo Cool Off 0.5 - 2 ^F DMDLCOFF 1
Cool Trend Demand Level 0.1 - 5 ^F CTRENDLV 0.1
Heat Trend Demand Level 0.1 - 5 ^F HTRENDLV 0.1
Cool Trend Time 30 - 600 sec CTRENDTM 120
Heat Trend Time 30 - 600 sec HTRENDTM 120
DMDL
Demand Limit Select 0 - 3 DMD_CTRL 0
Demand Limit at 20 ma 0 - 100 % DMT20MA 100
Loadshed Group Number 0 - 99 SHED_NUM 0
Loadshed Demand Delta 0 - 60 % SHED_DEL 0
Maximum Loadshed Time 0 - 120 min SHED_TIM 60
Demand Limit Sw.1 Setpt. 0 - 100 % DLSWSP1 80
Demand Limit Sw.2 Setpt. 0 - 100 % DLSWSP2 50
ECON
Economizer Installed ? Yes/No ECON_ENA Yes
Economizer Min.Position 0 - 100 % ECONOMIN 20
Economizer Max.Position 0 - 100 % ECONOMAX 98
Economzr trim for sumZ ? Yes/No ECONTRIM Yes
Econ ChangeOver Select 0 - 3 ECON_SEL 1
OA Enthalpy ChgOvr Selct 1 - 5 OAEC_SEL 2
Outdr.Enth Compare Value 18 - 28 OAEN_CFG 24
High OAT Lockout Temp 55 - 120 dF OAT_LOCK 60
OA Dewpoint Temp Limit 50 - 62 dF OADEWCFG 55
Outside Air RH Sensor Enable/Disable OARHSENS Disable
Economizer Control Type 1-3 ECON_CTL 1
Economizer Switch Config 0-2 ECOSWCFG 0
Economizer Prop.Gain 0.7 - 3.0 EC_PGAIN 1
Economizer Range Adjust 0.5 - 5 ^F EC_RANGE 2.5
Economizer Speed Adjust 0.1 - 10 EC_SPEED 0.75
Economizer Deadband 0.1 - 2 ^F EC_DBAND 0.5
Unoc Econ Free Cool Cfg 0-2 UEFC_CFG 0
Unoc Econ Free Cool Time 0-720 min UEFCTIME 120
Un.Ec.Free Cool OAT Lock 40-70 dF UEFCNTLO 50
EDTR
EDT Reset Configuration 0 - 3 EDRSTCFG 0
Reset Ratio 0 - 10 RTIO 2
Reset Limit 0 - 20 ^F LIMT 10
EDT 4-20 ma Reset Input Enable/Disable EDTRSENS Disable
