144
APPENDIX A — LOCAL DISPLAY TABLES (cont)
MODE — CONFIGURATION (cont)
ITEM EXPANSION RANGE UNITS CCN POINT DEFAULT PAGE NO.
COOL COOLING CONFIGURATION

Z.GN Capacity Threshold Adjst –10 - 10 Z_GAIN 1 39,46,91

MC.LO Compressor Lockout Temp –20 - 55 dF OATLCOMP 40 39,48

C.FOD Fan-Off Delay, Mech Cool 0 - 600 sec COOL_FOD 60 39

MLV Min. Load Valve? (HGBP) Yes/No MLV_SEL No 39,75

M.M. Motor Master Control Yes/No MOTRMAST No 39,49

HPSP Head Pressure Setpoint 80 - 150 dF HPSP 113 39,49

A1.EN Enable Compressor A1 Enable/Disable CMPA1ENA Enable 39

A2.EN Enable Compressor A2 Enable/Disable CMPA2ENA Enable 39

B1.EN Enable Compressor B1 Enable/Disable CMPB1ENA Enable 39

B2.EN Enable Compressor B2 Enable/Disable CMPB2ENA Enable 39

CS.A1 CSB A1 Feedback Alarm Enable/Disable CSB_A1EN Enable 39,100

CS.A2 CSB A2 Feedback Alarm Enable/Disable CSB_A2EN Enable 39,100

CS.B1 CSB B1 Feedback Alarm Enable/Disable CSB_B1EN Enable 39,100

CS.B2 CSB B2 Feedback Alarm Enable/Disable CSB_B2EN Enable 39,100

REV.R Rev Rotation Verified ? Yes/No REVR_VER No 39,98

H.SST Hi SST Alert Delay Time 5 - 30 min HSSTTIME 10 39,97
EDT.R EVAP.DISCHRGE TEMP RESET

RS.CF EDT Reset Configuration 0 - 3 (multi-text strings) EDRSTCFG 0 28,38

RTIO Reset Ratio 0 - 10 RTIO 2 28,38

LIMT Reset Limit 0 - 20 ^F LIMT 10 28,38

RES.S EDT 4-20 ma Reset Input Enable/Disable EDTRSENS Disable 28,35,38,96
HEAT HEATING CONFIGURATION

HT.CF Heating Control Type 0 - 4 HEATTYPE 0 50,51,56,71

HT.SP Heating Supply Air Setpt 80 - 120 dF SASPHEAT 85 50,51

OC.EN Occupied Heating Enabled Yes/No HTOCCENA No 51

LAT.M MBB Sensor Heat Relocate Yes/No HTLATMON No 51

G.FOD Fan-Off Delay, Gas Heat 45-600 GAS_FOD 45 51

E.FOD Fan-Off Delay, Elec Heat 10-600 HEAT_FOD 30 51

SG.CF STAGED GAS CONFIGS

SG.CF

HT.ST Staged Gas Heat Type 0 - 4 HTSTGTYP 0 51,53-56

SG.CF

CAP.M Max Cap Change per Cycle 5 - 45 HTCAPMAX 45 51,53,54

SG.CF

M.R.DB S.Gas DB min.dF/PID Rate 0 - 5 HT_MR_DB 0.5 51,53,54

SG.CF

S.G.DB St.Gas Temp. Dead Band 0 - 5 ^F HT_SG_DB 2 51,53,54

SG.CF

RISE Heat Rise dF/sec Clamp 0.05 - 0.2 HTSGRISE 0.06 51,53,54

SG.CF

LAT.L LAT Limit Config 0 - 20 ^F HTLATLIM 10 51,53,54

SG.CF

LIM.M Limit Switch Monitoring? Yes/No HTLIMMON No 51,53,54

SG.CF

SW.H.T Limit Switch High Temp 110 - 180 dF HT_LIMHI 170 51,53,54

SG.CF

SW.L.T Limit Switch Low Temp 100 - 170 dF HT_LIMLO 160 51,53,54

SG.CF

HT.P Heat Control Prop. Gain 0 - 1.5 HT_PGAIN 1 51,53,54

SG.CF

HT.D Heat Control Derv. Gain 0 - 1.5 HT_DGAIN 1 51,53,54

SG.CF

HT.TM Heat PID Rate Config 60 - 300 sec HTSGPIDR 90 51,53,54
SP SUPPLY STATIC PRESS.CFG.

SP.CF Static Pressure Config 0 - 1 (multi-text strings) STATICFG No 31,57,58,60

SP.FN Static Pres.Fan Control? Yes STATPFAN Yes 57,58

SP.S Static Pressure Sensor Enable/Disable SPSENS Disable 57,58

SP.LO Static Press. Low Range –10 - 0 SP_LOW 0 57,58

SP.HI Static Press. High Range 0 - 10 SP_HIGH 5 57,58

SP.SP Static Pressure Setpoint 0 - 5 "H2O SPSP 1.5 28,57,58

SP.MN VFD Minimum Speed 0 - 100 % STATPMIN 20 58

SP.MX VFD Maximum Speed 0 - 100 % STATPMAX 100 58

SP.FS VFD Fire Speed Override 0 - 100 % STATPFSO 100 58,67

SP.RS Stat. Pres. Reset Config 0-4 (multi-text strings) SPRSTCFG 0 31,58,59

SP.RT SP Reset Ratio (
/dF)
0 - 2.00 SPRRATIO 0.2 58

SP.LM SP Reset Limit in iwc( ) 0 - 2.00 SPRLIMIT 0.75 58

SP.EC SP Reset Econo.Position 0 - 100 % ECONOSPR 5 58

S.PID STAT.PRESS.PID CONFIGS 58,59

S.PID->SP.TM Stat.Pres.PID Run Rate 1 - 200 sec SPIDRATE 2 58,59

S.PID->SP.P Static Press. Prop. Gain 0 - 100 STATP_PG 20 58,59

S.PID->SP.I Static Pressure Intg. Gain 0 - 50 STATP_IG 2 58,59

S.PID->SP.D Static Pressure Derv. Gain 0 - 50 STATP_DG 0 58,59

S.PID->SP.SG Static Press.System Gain 0 - 50 STATP_SG 1 58,59
ECON ECONOMIZER CONFIGURATION

EC.EN Economizer Installed? Yes/No ECON_ENA Yes 28,60,62

EC.MN Economizer Min.Position 0 - 100 % ECONOMIN 5 28,60,62

EC.MX Economizer Max.Position 0 - 100 % ECONOMAX 98 28,42,43,50,60,
62

E.TRM Economzr Trim For SumZ ? Yes/No ECONTRIM Yes 28,48,60,62

E.SEL Econ ChangeOver Select 0 - 3 (multi-text strings) ECON_SEL 1 28,61,62

OA.E.C OA Enthalpy ChgOvr Selct 1 - 5 (multi-text strings) OAEC_SEL 4 28,61,62

OA.EN Outdr.Enth Compare Value 18 - 28 OAEN_CFG 24 28,61,62

OAT.L High OAT Lockout Temp -40 - 120 dF OAT_LOCK 60 28,61,62

O.DEW OA Dewpoint Temp Limit 50 - 62 dF OADEWCFG 55 28,61,62

ORH.S Outside Air RH Sensor Enable/Disable OARHSENS Disable 28,61,62,96

E.TYP Economizer Control Type 1-3 (multi-text strings) ECON_CTL 1 61,62

EC.SW Economizer Switch Config 0 - 2 (multi-text strings) ECOSWCFG 0 61,62

E.CFG ECON.OPERATION CONFIGS

E.CFG

E.P.GN Economizer Prop.Gain 0.7 - 3.0 EC_PGAIN 1 62

E.CFG

E.RNG Economizer Range Adjust 0.5 - 5.0 ^F EC_RANGE 2.5 62

E.CFG

E.SPD Economizer Speed Adjust 0.1 - 10.0 EC_SPEED 0.75 62

E.CFG

E.DBD Economizer Deadband 0.1 - 2.0 ^F EC_DBAND 0.5 62

UEFC UNOCC.ECON.FREE COOLING

UEFC

FC.CF Unoc Econ Free Cool Cfg 0-2 (multi-text strings) UEFC_CFG 0 62

UEFC

FC.TM Unoc Econ Free Cool Time 0 - 720 min UEFCTIME 120 62

UEFC

FC.L.O Un.Ec.Free Cool OAT Lock 40 - 70 dF UEFCNTLO 50 62
