Carrier WEATHERMAKER 48/50AJ User Manual
Page 145
145
APPENDIX A — LOCAL DISPLAY TABLES (cont)
MODE — CONFIGURATION (cont)
ITEM
EXPANSION
RANGE
UNITS
CCN POINT DEFAULT
PAGE NO.
BP
BUILDING PRESS. CONFIG
BP.CF
Building Press. Config
0-3
BLDG_CFG
0
29,64,65
BP.RT
Bldg.Pres.PID Run Rate
5-120
sec
BPIDRATE
10
64,65
BP.P
Bldg. Press. Prop. Gain
0-5
BLDGP_PG
0.5
64,65
BP.I
Bldg.Press.Integ.Gain
0-2
BLDGP_IG
0.5
64,65
BP.D
Bldg.Press.Deriv.Gain
0-5
BLDGP_DG
0.3
64,65
BP.SO
BP Setpoint Offset
0.0 - 0.5
“H2O
BPSO
0.05
64,65
BP.MN
BP VFD Minimum Speed
0-100
%
BLDGPMIN
10
64,65
BP.MX
BP VFD Maximum Speed
0-100
%
BLDGPMAX
100
64,65
BP.FS
VFD/Act. Fire Speed/Pos.
0-100
%
BLDGPFSO
100
64,65
BP.MT
Power Exhaust Motors
1-2
PWRM
1
64,65
BP.S
Building Pressure Sensor
Enable/Dsable
BPSENS
Dsable
64,65
BP.R
Bldg Press (+/-) Range
0 - 1.00
“H2O
BP_RANGE
0.25
64,65
BP.SP
Building Pressure Setp.
–0.25 -> 0.25
"H2O
BPSP
0.05
29,64,65
BP.P1
Power Exhaust On Setp.1
0 - 100
%
PES1
35
29,64,65
BP.P2
Power Exhaust On Setp.2
0 - 100
%
PES2
75
29,64,65
B.CFG
BP ALGORITHM CONFIGS
64,65
B.CFG
BP.SL
Modulating PE Alg. Slct.
1-3
BPSELECT
1
64,65
B.CFG
BP.TM
BP PID Evaluation Time
0 - 10
min
BPPERIOD
1
64,65
B.CFG
BP.ZG
BP Threshold Adjustment
0.1 - 10.0
“H2O
BPZ_GAIN
1
64,65
B.CFG
BP.HP
High BP Level
0 - 1.000
“H2O
BPHPLVL
0.05
64,65
B.CFG
BP.LP
Low BP Level
0 - 1.000
“H2O
BPLPLVL
0.04
64-66
D.LV.T
COOL/HEAT SETPT. OFFSETS
L.H.ON
Dmd Level Lo Heat On
–1 - 2
^F
DMDLHON
1.5
27,28,52
H.H.ON
Dmd Level(+) Hi Heat On
0.5 - 20.0
^F
DMDHHON
0.5
27,28,52
L.H.OF
Dmd Level(-) Lo Heat Off
0.5 - 2
^F
DMDLHOFF
1
27,28,52
L.C.ON
Dmd Level Lo Cool On
–1 - 2
^F
DMDLCON
1.5
27,28,52
H.C.ON
Dmd Level(+) Hi Cool On
0.5 - 20.0
^F
DMDHCON
0.5
27,28,52
L.C.OF
Dmd Level(-) Lo Cool Off
0.5 - 2
^F
DMDLCOFF
1
27,28,52
C.T.LV
Cool Trend Demand Level
0.1 - 5
^F
CTRENDLV
0.1
52
H.T.LV
Heat Trend Demand Level
0.1 - 5
^F
HTRENDLV
0.1
52
C.T.TM
Cool Trend Time
30 - 600
sec
CTRENDTM 120
52
H.T.TM
Heat Trend Time
30 - 600
sec
HTRENDTM 120
52
DMD.L
DEMAND LIMIT CONFIG.
DM.L.S
Demand Limit Select
0 - 3 (multi-text strings)
DMD_CTRL
0
31,35,48,49,98
D.L.20
Demand Limit at 20 ma
0 - 100
%
DMT20MA
100
31,49
SH.NM
Loadshed Group Number
0 - 99
SHED_NUM 0
49
SH.DL
Loadshed Demand Delta
0 - 60
%
SHED_DEL
0
49
SH.TM
Maximum Loadshed Time
0 - 120
min
SHED_TIM
60
49
D.L.S1
Demand Limit Sw.1 Setpt.
0 - 100
%
DLSWSP1
80
31,49
D.L.S2
Demand Limit Sw.2 Setpt.
0 - 100
%
DLSWSP2
50
31,49
IAQ
INDOOR AIR QUALITY CFG.
DCV.C
DCV ECONOMIZER SETPOINTS
DCV.C
EC.MN
Economizer Min.Position
0 - 100
%
ECONOMIN
5
29,31,32,67-70
DCV.C
IAQ.M
IAQ Demand Vent Min.Pos.
0 - 100
%
IAQMINP
0
29,31,67-70
AQ.CF
AIR QUALITY CONFIGS
AQ.CF
IQ.A.C
IAQ Analog Sensor Config
0 - 4 (multi-text strings)
IAQANCFG
0
32,67,69,70
AQ.CF
IQ.A.F
IAQ 4-20 ma Fan Config
0 - 2 (multi-text strings)
IAQANFAN
0
32,68-70
AQ.CF
IQ.I.C
IAQ Discrete Input Config
0 - 2 (multi-text strings)
IAQINCFG
0
31,35,67-70
AQ.CF
IQ.I.F
IAQ Disc.In. Fan Config
0 - 2 (multi-text strings)
IAQINFAN
0
32,68-70
AQ.CF
OQ.A.C
OAQ 4-20ma Sensor Config
0 - 2 (multi-text strings)
OAQANCFG 0
35,68-70
AQ.SP
AIR QUALITY SETPOINTS
AQ.SP
IQ.O.P
IAQ Econ Override Pos.
0 - 100
%
IAQOVPOS
100
32,67,69,70,98
AQ.SP
DAQ.L
Diff.Air Quality LoLimit
0 - 1000
DAQ_LOW
100
68-70
AQ.SP
DAQ.H
Diff.Air Quality HiLimit
100 - 2000
DAQ_HIGH
700
32,68-70
AQ.SP
D.F.OF
DAQ PPM Fan Off Setpoint
0 - 2000
DAQFNOFF
200
32,68-70
AQ.SP
D.F.ON
DAQ PPM Fan On Setpoint
0 - 2000
DAQFNON
400
32,68-70
AQ.SP
IAQ.R
Diff. AQ Responsiveness
–5 - 5
IAQREACT
0
69,70
AQ.SP
OAQ.L
OAQ Lockout Value
0 - 2000
OAQLOCK
0
69,70
AQ.SP
OAQ.U
User Determined OAQ
0 - 5000
OAQ_USER
400
32,69,70
AQ.S.R
AIR QUALITY SENSOR RANGE
AQ.S.R
IQ.R.L
IAQ Low Reference
0 - 5000
IAQREFL
0
32,69,70
AQ.S.R
IQ.R.H
IAQ High Reference
0 - 5000
IAQREFH
2000
32,69,70
AQ.S.R
OQ.R.L
OAQ Low Reference
0 - 5000
OAQREFL
0
69,70
AQ.S.R
OQ.R.H
OAQ High Reference
0 - 5000
OAQREFH
2000
69,70
IAQ.P
IAQ PRE-OCCUPIED PURGE
IAQ.P
IQ.PG
IAQ Purge
Yes/No
IAQPURGE
No
69,70
IAQ.P
IQ.P.T
IAQ Purge Duration
5-60
min
IAQPTIME
15
69,70
IAQ.P
IQ.P.L
IAQ Purge LoTemp Min Pos
0-100
%
IAQPLTMP
10
69,70
IAQ.P
IQ.P.H
IAQ Purge HiTemp Min Pos
0-100
%
IAQPHTMP
35
69,70
IAQ.P
IQ.L.O
IAQ Purge OAT Lockout
35-70
dF
IAQPNTLO
50
69,70
DEHU
DEHUMIDIFICATION CONFIG.
D.SEL
Dehumidification Config
0-2 (multi-text strings)
DHSELECT
0
69-71
D.SEN
Dehumidification Sensor
1-2 (multi-text strings)
DHSENSOR 1
69,70
D.EC.D
Econ disable in DH mode?
Yes/No
DHECDISA
Yes
69,70
D.V.CF
Vent Reheat Setpt Select
0-1 (multi-text strings)
DHVHTCFG
0
70,71
D.V.RA
Vent Reheat RAT offset
0-8
^F
DHVRAOFF
0
70,71
D.V.HT
Vent Reheat Setpoint
55-95
dF
DHVHT_SP
70
70,71
D.C.SP
Dehumidify Cool Setpoint
40-55
dF
DHCOOLSP 45
70,71
D.RH.S
Dehumidify RH Setpoint
10-90
%
DHRELHSP
55
70,71
