Page 158
158
APPENDIX B — CCN TABLES (cont)
MAINTENANCE DISPLAY TABLES (cont)
TABLE
DISPLAY NAME
RANGE
UNITS
POINT NAME
WRITE STATUS
ENTHALPY
Outdoor Air Enthalpy
OAE
Outside Air Temperature
dF
OAT
forcible
Outside Air Rel.Humidity
%
OARH
forcible
Outside Air RH Sensor
OARHSENS
config
OA Dewpoint Temp Limit
dF
OADEWCFG
config
OutsideAir DewPoint Temp
dF
OADEWTMP
OutsideAir Humidty Ratio
OA_HUMR
OA H2O Vapor Sat.Pressur
"Hg
OA_PWS
OA H2O Partial.Press.Vap
"Hg
OA_PWS
Return Air Enthalpy
RAE
Return Air Temperature
dF
RAT
forcible
Controlling Return Temp
dF
RETURN_T
forcible
Return Air Rel.Humidity
%
RARH
forcible
Return Air Temp Sensor
RATSENS
config
Return Air RH Sensor
RARHSENS
config
Altitude……..in feet:
ALTITUDE
config
Atmospheric Pressure
"Hg
ATMOPRES
config
LINKDATA
Supervisory Element #
SUPE-ADR
Supervisory Bus
SUPE-BUS
Supervisory Block Number
BLOCKNUM
Average Occup. Heat Stp.
dF
AOHS
Average Occup. Cool Stp.
dF
AOCS
Average Unocc. Heat Stp.
dF
AUHS
Average Unocc. Cool Stp.
dF
AUCS
Average Zone Temperature
dF
AZT
Average Occup. Zone Temp
dF
AOZT
Linkage System Occupied?
LOCC
Next Occupied Day
LNEXTOCD
Next Occupied Time
LNEXTOCC
Next Unoccupied Day
LNEXTUOD
Next Unoccupied Time
LNEXTUNC
Last Unoccupied Day
LLASTUOD
Last Unoccupied Time
LLASTUNC
MILLIAMP
IAQ milliamps
ma
IAQ_MA
OAQ milliamps
ma
OAQ_MA
SP Reset milliamps
ma
SPRST_MA
4-20 ma Demand Signal
ma
DMDLMTMA
forcible
EDT Reset milliamps
ma
EDTRESMA
OARH milliamps
ma
OARH_MA
RARH milliamps
ma
RARH_MA
BP milliamps
ma
BP_MA
SP milliamps
ma
SP_MA
MODES
System Mode…………:
ascii text strings
HVAC Mode…………..:
ascii text strings
Control Mode………..:
ascii text strings
Currently Occupied
On/Off
MODEOCCP
Timed Override in effect
On/Off
MODETOVR
DCV resetting min pos
On/Off
MODEADCV
Supply Air Reset
On/Off
MODESARS
Demand Limit in Effect
On/Off
MODEDMLT
Temp.Compensated Start
On/Off
MODETCST
IAQ pre-occ purge active
On/Off
MODEIQPG
Linkage Active - DAV
On/Off
MODELINK
Mech.Cooling Locked Out
On/Off
MODELOCK
HVAC Mode Numerical Form
0-24
MODEHVAC
OCCDEFME
Current Day, Time & Date:
ascii date & time
TIMEDATE
Occupancy Controlled By:
ascii text
OCDFTXT1
ascii text
OCDFTXT2
ascii text
OCDFTXT3
Currently Occupied
Yes/No
MODE_OCC
Current Occupied Time
STRTTIME
Current Unoccupied Time
ENDTIME
Next Occupied Day & Time
NXTOC_DT
Next Unocc. Day & Time
NXTUN_DT
Last Unocc. Day & Time
PRVUN_DT
Current Occup. Period #
PER_NO
Timed-Override in Effect
Yes/No
OVERLAST
Timed-Override Duration
hours
OVR_HRS
