ITEM
EXPANSION
RANGE
DEFAULT
ENTRY
AQ.S.R
IQ.R.L
IAQ Low Reference
0 - 5000
0
AQ.S.R
IQ.R.H
IAQ High Reference
0 - 5000
2000
AQ.S.R
OQ.R.L
OAQ Low Reference
0 - 5000
0
AQ.S.R
OQ.R.H
OAQ High Reference
0 - 5000
2000
IAQ.P
IAQ PRE-OCCUPIED PURGE
IAQ.P
IQ.PG
IAQ Purge
Yes/No
No
IAQ.P
IQ.P.T
IAQ Purge Duration
5-60 min
15
IAQ.P
IQ.P.L
IAQ Purge LoTemp Min Pos
0-100 %
10
IAQ.P
IQ.P.H
IAQ Purge HiTemp Min Pos
0-100 %
35
IAQ.P
IQ.L.O
IAQ Purge OAT Lockout
35-70 dF
50
DEHU
DEHUMIDIFICATION CONFIG.
D.SEL
Dehumidification Config
0-2(multi-text strings)
0
D.SEN
Dehumidification Sensor
1-2(multi-text strings)
1
D.EC.D
Econ disable in DH mode?
Yes/No
Yes
D.V.CF
Vent Reheat Setpt Select
0-1(multi-text strings)
0
D.V.RA
Vent Reheat RAT offset
0-8 ^F
0
D.V.HT
Vent Reheat Setpoint
55-95 dF
70
D.C.SP
Dehumidify Cool Setpoint
40-55 dF
45
D.RH.S
Dehumidify RH Setpoint
10-90 %
55
CCN
CCN CONFIGURATION
CCNA
CCN Address
1 - 239
1
CCNB
CCN Bus Number
0 - 239
0
BAUD
CCN Baud Rate
1 - 5 (multi-text strings)
3
BROD
CCN BROADCST DEFINITIONS
BROD
TM.DT
CCN Time/Date Broadcast
ON/OFF
On
BROD
OAT.B
CCN OAT Broadcast
ON/OFF
Off
BROD
ORH.B
CCN OARH Broadcast
ON/OFF
Off
BROD
OAQ.B
CCN OAQ Broadcast
ON/OFF
Off
BROD
G.S.B
Global Schedule Broadcst
ON/OFF
Off
BROD
B.ACK
CCN Broadcast Ack'er
ON/OFF
Off
SC.OV
CCN SCHEDULES-OVERRIDES
SC.OV
SCH.N
Schedule Number
0 - 99
1
SC.OV
HOL.T
Accept Global Holidays?
YES/NO
No
SC.OV
O.T.L.
Override Time Limit
0 - 4 HRS
1
SC.OV
OV.EX
Timed Override Hours
0 - 4 HRS
0
SC.OV
SPT.O
SPT Override Enabled ?
YES/NO
Yes
SC.OV
T58.O
T58 Override Enabled ?
YES/NO
Yes
SC.OV
GL.OV
Global Sched. Override ?
YES/NO
No
ALLM
ALERT LIMIT CONFIG.
SP.L.O
SPT lo alert limit/occ
–10-245 dF
60
SP.H.O
SPT hi alert limit/occ
–10-245 dF
85
SP.L.U
SPT lo alert limit/unocc
–10-245 dF
45
SP.H.U
SPT hi alert limit/unocc
–10-245 dF
100
SA.L.O
EDT lo alert limit/occ
–40-245 dF
40
SA.H.O
EDT hi alert limit/occ
–40-245 dF
100
SA.L.U
EDT lo alert limit/unocc
–40-245 dF
40
SA.H.U
EDT hi alert limit/unocc
–40-245 dF
100
RA.L.O
RAT lo alert limit/occ
–40-245 dF
60
RA.H.O
RAT hi alert limit/occ
–40-245 dF
90
RA.L.U
RAT lo alert limit/unocc
–40-245 dF
40
RA.H.U
RAT hi alert limit/unocc
–40-245 dF
100
R.RH.L
RARH low alert limit
0-100 %
0
R.RH.H
RARH high alert limit
0-100 %
100
SP.L
SP low alert limit
0-5 "H2O
0
SP.H
SP high alert limit
0-5 "H2O
2
BP.L
BP lo alert limit
–0.25-0.25 "H2O
-0.25
BP.H
BP high alert limit
–0.25-0.25 "H2O
0.25
IAQ.H
IAQ high alert limit
0-5000
1200
TRIM
SENSOR TRIM CONFIG.
SAT.T
Air Temp Lvg SF Trim
–10 - 10 ^F
0
RAT.T
RAT Trim
–10 - 10 ^F
0
OAT.T
OAT Trim
–10 - 10 ^F
0
SPT.T
SPT Trim
–10 - 10 ^F
0
CTA.T
Cir A Sat.Cond.Temp Trim
–30 - 30 ^F
0
CTB.T
Cir B Sat.Cond.Temp Trim
–30 - 30 ^F
0
SP.A.T
Suct.Press.Circ.A Trim
–50 - 50 PSIG
0
SP.B.T
Suct.Press.Circ.B Trim
–50 - 50 PSIG
0
DP.A.T
Dis.Press.Circ.A Trim
–50 - 50 PSIG
0
DP.B.T
Dis.Press.Circ.B Trim
–50 - 50 PSIG
0
