Carrier WEATHERMAKER 48/50AJ - Manual (Page 152)

152
APPENDIX B — CCN TABLES (cont)
CONFIG TABLES (cont)
SERVICE-CONFIG TABLES
TABLE NAME RANGE UNITS POINT NAME DEFAULT
SCHEDOVR
Schedule Number 0-99 SCHEDNUM 0
Accept Global Holidays? Yes/No HOLIDAYT No
Override Time Limit 0-4 hours OTL 1
Timed Override Hours 0-4 hours OVR_EXT 0
Accepting an Override:
SPT Override Enabled ?
Yes/No SPT_OVER Yes
T58 Override Enabled ? Yes/No T58_OVER Yes
Allowed to Broadcast a
Global Sched. Override ?
Yes/No GLBLOVER No
SET_PNT
Occupied Heat Setpoint 55-80 dF OHSP 68
Occupied Cool Setpoint 55-80 dF OCSP 75
Unoccupied Heat Setpoint 40-80 dF UHSP 55
Unoccupied Cool Setpoint 75-95 dF UCSP 90
Heat-Cool Setpoint Gap 2-10 ^F HCSP_GAP 5
VAV Occ. Cool On Delta 0-25 ^F VAVOCON 3.5
VAV Occ. Cool Off Delta 1-25 ^F VAVOCOFF 2
Supply Air Setpoint 45-75 dF SASP 55
Supply Air Setpoint Hi 45-75 dF SASP_HI 55
Supply Air Setpoint Lo 45-75 dF SASP_LO 60
Heating Supply Air Setpt 90-145 dF SASPHEAT 85
Tempering Purge SASP –20-80 dF TEMPPURG 50
TABLE NAME RANGE UNITS POINT NAME DEFAULT
ALLM
SPT lo alert limit/occ –10-245 dF SPLO 60
SPT hi alert limit/occ –10-245 dF SPHO 85
SPT lo alert limit/unocc –10-245 dF SPLU 45
SPT hi alert limit/unocc –10-245 dF SPHU 100
EDT lo alert limit/occ –40-245 dF SALO 40
EDT hi alert limit/occ –40-245 dF SAHO 100
EDT lo alert limit/unocc –40-245 dF SALU 40
EDT hi alert limit/unocc –40-245 dF SAHU 100
RAT lo alert limit/occ –40-245 dF RALO 60
RAT hi alert limit/occ –40-245 dF RAHO 90
RAT lo alert limit/unocc –40-245 dF RALU 40
RAT hi alert limit/unocc –40-245 dF RAHU 100
RARH low alert limit 0-100 % RRHL 0
RARH high alert limit 0-100 % RRHH 100
SP low alert limit 0-5 "H2O SPL 0
SP high alert limit 0-5 "H2O SPH 2
BP lo alert limit –0.25-0.25 "H2O BPL -0.25
BP high alert limit –0.25-0.25 "H2O BPH 0.25
IAQ high alert limit 0-5000 IAQH 1200
BP__
Building Press. Config 0-3 BLDG_CFG 0
Bldg.Pres.PID Run Rate 5-120 BPIDRATE 10
Bldg. Press. Prop. Gain 0-5 BLDGP_PG 0.5
Bldg.Press.Integ.Gain 0-2 BLDGP_IG 0.5
Bldg.Press.Deriv.Gain 0-5 BLDGP_DG 0.3
BP Setpoint Offset 0.0 - 0.5 BPSO 0.05
BP VFD Minimum Speed 0-100 BLDGPMIN 10
BP VFD Maximum Speed 0-100 BLDGPMAX 100
VFD/Act. Fire Speed/Pos. 0-100 BLDGPFSO 100
Power Exhaust Motors 0-2 PWRM 1
0=None,1=4 Mtr, 2=6 Mtr
Building Pressure Sensor
Enable/Disable BPSENS Dsable
Bldg Press (+/-) Range 0-1 BP_RANGE 0.25
Building Pressure Setp. –0.25 -> 0.25 "H2O BPSP 0.05
Power Exhaust On Setp.1 0-100 % PES1 35
Power Exhaust On Setp.2 0-100 % PES2 75
Modulating PE Alg. Slct. 1-3 BPSELECT 1
BP PID Evaluation Time 0-10 min BPPERIOD 1
BP Threshold Adjustment 0.1-10 BPZ_GAIN 1
High BP Level 0-1 BPHPLVL 0.05
Low BP Level 0-1 BPLPLVL 0.04
