CL-2
-
- -
- -
-
- -
-
- -
-
- -
-
- -
- -
-
- -
-
- -
-
- -
- -
-
- -
-
- -
-
- -
-
- -
- -
-
- -
-
- -
-
- -
-
- -
- -
-
- -
-
- -
-
- -
- -
-
- -
-
- -
-
- -
-
- -
- -
-
- -
-
- -
-
- -
- -
-
- -
-
- -
-
- -
-
- -
- -
-
- -
-
- -
-
- -
-
- -
- -
-
- -
-
- -
-
- -
- -
-
- -
-
- -
-
- -
-
- -
- -
-
- -
-
- -
-
- -
- -
-
- -
-
- -
-
- -
-
- -
- -
-
--
- -
-
- -
- -
-
- -
-
- -
-
- -
- - -
CUT
AL
ONG DO
TT
E
D
LINE
CU
T ALONG DO
TT
E
D
LINE
ITEM
EXPANSION
RANGE
DEFAULT
ENTRY
HEAT
HEATING CONFIGURATION
HT.CF
Heating Control Type
0 - 4
0
HT.SP
Heating Supply Air Setpt
80 - 120 dF
85
OC.EN
Occupied Heating Enabled
Yes/No
No
LAT.M
MBB Sensor Heat Relocate
Yes/No
No
G.FOD
Fan-Off Delay, Gas Heat
45-600
45
E.FOD
Fan-Off Delay, Elec Heat
10-600
30
SG.CF
STAGED GAS CONFIGS
SG.CF
HT.ST
Staged Gas Heat Type
0 - 4
0
SG.CF
CAP.M
Max Cap Change per Cycle
5 - 45
45
SG.CF
M.R.DB
S.Gas DB min.dF/PID Rate
0 - 5
0.5
SG.CF
S.G.DB
St.Gas Temp. Dead Band
0 - 5 ^F
2
SG.CF
RISE
Heat Rise dF/sec Clamp
0.05 - 0.2
0.06
SG.CF
LAT.L
LAT Limit Config
0 - 20 ^F
10
SG.CF
LIM.M
Limit Switch Monitoring?
Yes/No
No
SG.CF
SW.H.T
Limit Switch High Temp
110 - 180 dF
170
SG.CF
SW.L.T
Limit Switch Low Temp
100 - 170 dF
160
SG.CF
HT.P
Heat Control Prop. Gain
0 - 1.5
1
SG.CF
HT.D
Heat Control Derv. Gain
0 - 1.5
1
SG.CF
HT.TM
Heat PID Rate Config
60 - 300 sec
90
SP
SUPPLY STATIC PRESS.CFG.
SP.CF
Static Pressure Config
0 - 1 (multi-text strings)
No
SP.FN
Static Pres.Fan Control?
Yes
Yes
SP.S
Static Pressure Sensor
Enable/Disable
Disable
SP.LO
Static Press. Low Range
-10 - 0
0
SP.HI
Static Press. High Range
0 - 10
5
SP.SP
Static Pressure Setpoint
0 - 5 "H2O
1.5
SP.MN
VFD Minimum Speed
0 - 100 %
20
SP.MX
VFD Maximum Speed
0 - 100 %
100
SP.FS
VFD Fire Speed Override
0 - 100 %
100
SP.RS
Stat. Pres. Reset Config
0 - 4 (multi-text strings)
0
SP.RT
SP Reset Ratio (
/dF)
0 - 2.00 in. wg/dF
0.2
SP.LM
SP Reset Limit in iwc (
)
0 - 2.00 in. wg
0.75
SP.EC
SP Reset Econo. Position
0 - 100 %
5
S.PID
STAT.PRESS.PID CONFIGS
S.PID
SP.TM
Stat.Pres.PID Run Rate
1 - 200 sec
2
S.PID
SP.P
Static Press. Prop. Gain
0 - 100
20
S.PID
SP.I
Static Pressure Intg. Gain
0 - 50
2
S.PID
SP.D
Static Pressure Derv. Gain
0 - 50
0
S.PID
SP.SG
Static Press.System Gain
0 - 50
1
ECON
ECONOMIZER CONFIGURATION
EC.EN
Economizer Installed?
Yes/No
Yes
EC.MN
Economizer Min.Position
0 - 100 %
5
EC.MX
Economizer Max.Position
0 - 100 %
98
E.TRM
Economzr Trim For SumZ ?
Yes/No
Yes
E.SEL
Econ ChangeOver Select
0 - 3 (multi-text strings)
1
OA.E.C
OA Enthalpy ChgOvr Selct
1 - 5 (multi-text strings)
4
OA.EN
Outdr.Enth Compare Value
18 - 28
24
OAT.L
High OAT Lockout Temp
–40 - 120 dF
60
O.DEW
OA Dewpoint Temp Limit
50 - 62 dF
55
ORH.S
Outside Air RH Sensor
Enable/Disable
Disable
E.TYP
Economizer Control Type
1-3 (multi-text strings)
1
EC.SW
Economizer Switch Config
0 - 2 (multi-text strings)
0
E.CFG
ECON.OPERATION CONFIGS
E.CFG
E.P.GN
Economizer Prop.Gain
0.7 - 3.0
1
E.CFG
E.RNG
Economizer Range Adjust
0.5 - 5.0 ^F
2.5
E.CFG
E.SPD
Economizer Speed Adjust
0.1 - 10.0
0.75
E.CFG
E.DBD
Economizer Deadband
0.1 - 2.0 ^F
0.5
UEFC
UNOCC.ECON.FREE COOLING
UEFC
FC.CF
Unoc Econ Free Cool Cfg
0-2 (multi-text strings)
0
UEFC
FC.TM
Unoc Econ Free Cool Time
0 - 720 min
120
UEFC
FC.L.O
Un.Ec.Free Cool OAT Lock
40 - 70 dF
50
