APPENDIX E — UPC OPEN CONTROLLER (cont)
NETWORK POINTS LIST (cont)
See legend on page 182.
BACNET
OBJECT ID
POINT NAME
READ
ONLY
UNITS
DEFAULT
VALUE
RANGE
BACNET
OBJECT NAME
UNIT
POINT
BV:9
Alarm State
R
n/a
n/a
n/a
alm_1
ALM
BV:10
Capacity Clamp Mode
R
n/a
n/a
n/a
capmode_1
CAPMODE
BV:11
Fan request from IGC
R
n/a
n/a
n/a
igcfan_1
IGCFAN
BV:12
Comp A1 Locked Out ?
R
n/a
n/a
n/a
cmpa1lok_1
CMPA1LOK
BV:13
Comp A2 Locked Out ?
R
n/a
n/a
n/a
cmpa2lok_1
CMPA2LOK
BV:14
Comp B1 Locked Out ?
R
n/a
n/a
n/a
cmpb1lok_1
CMPB1LOK
BV:15
Comp B2 Locked Out ?
R
n/a
n/a
n/a
cmpb2ok_1
CMPB2LOK
BV:16
Compressor A1 Relay
R
n/a
n/a
n/a
cmpa1_1
CMPA1
BV:17
Compressor A2 Relay
R
n/a
n/a
n/a
cmpa2_1
CMPA2
BV:18
Compressor B1 Relay
R
n/a
n/a
n/a
cmpb1_1
CMPB1
BV:19
Compressor B2 Relay
R
n/a
n/a
n/a
cmpb2_1
CMPB2
BV:20
Cool Mode Not In Effect?
R
n/a
n/a
n/a
cool_off_1
COOL_OFF
BV:21
Override Modes in Effect
R
n/a
n/a
n/a
modes_1
MODES
BV:22
Supply Fan not on 30s ?
R
n/a
n/a
n/a
sfonstat_1
SFONSTAT
BV:25
DBC - OAT Lockout?
R
n/a
n/a
n/a
dbc_stat_1
DBC_STAT
BV:26
DCV Resetting Min Pos
R
n/a
n/a
n/a
modeadcv_1
MODEADCV
BV:27
DDBC- OAT > RAT Lockout?
R
n/a
n/a
n/a
ddbcstat_1
DDBCSTAT
BV:28
DEC - Diff.Enth.Lockout?
R
n/a
n/a
n/a
dec_stat_1
DEC_STAT
BV:29
Dehumid. Disabled Econ.?
R
n/a
n/a
n/a
dhdisabl_1
DHDISABL
BV:30
Dehumidify Input
W
n/a
n/a
0-1
dhdiscin_1
DHDISCIN
BV:31
Demand Limit In Effect
R
n/a
n/a
n/a
modedmlt_1
MODEDMLT
BV:32
DEW - OA Dewpt.Lockout?
R
n/a
n/a
n/a
dew_stat_1
DEW_STAT
BV:34
Econ Act. Unavailable?
R
n/a
n/a
n/a
econunav_1
ECONUNAV
BV:35
Econ disable in DH mode?
W
n/a
1
0-1
dhecdisa_1
DHECDISA
BV:36
Economizer Active?
R
n/a
n/a
n/a
ecactive_1
ECACTIVE
BV:37
Economizer Control Input
W
n/a
n/a
0-1
ecosw_1
ECOSW
BV:38
Economizer Forced ?
R
n/a
n/a
n/a
econforc_1
ECONFORC
BV:41
Econo Position Override
W
n/a
n/a
0-1
ecooride_1
ECOORIDE
BV:42
Econ Recovery Hold Off?
R
n/a
n/a
n/a
econheld_1
ECONHELD
BV:44
EDT Sensor Bad ?
R
n/a
n/a
n/a
edt_stat_1
EDT_STAT
BV:45
Emergency Stop
W
n/a
n/a
0-1
emstop_1
EMSTOP
BV:46
Enable Compressor A1
W
n/a
Enable
0-1
cmpa1ena_1
CMPA1ENA
BV:47
Enable Compressor A2
W
n/a
Enable
0-1
cmpa2ena_1
CMPA2ENA
BV:48
Enable Compressor B1
W
n/a
Enable
0-1
cmpb1ena_1
CMPB1ENA
BV:49
Enable Compressor B2
W
n/a
Enable
0-1
cmpb2ena_1
CMPB2ENA
BV:50
Fan Fail Shuts Down Unit
W
n/a
0
0-1
sfs_shut_1
SFS_SHUT
BV:52
Heat Relay 1
R
n/a
n/a
n/a
hs1_1
HS1
BV:53
Heat Relay 2
R
n/a
n/a
n/a
hs2_1
HS2
BV:54
High BP Override
R
n/a
n/a
n/a
bphpovrd_1
BPHPOVRD
BV:55
Hi Limit Switch Tmp Mode
R
n/a
n/a
n/a
limtmode_1
LIMTMODE
BV:56
IAQ Pre-Occ Purge Active
R
n/a
n/a
n/a
modeiqpg_1
MODEIQPG
BV:57
IAQ Purge
W
n/a
0
0-1
iaqpurge_1
IAQPURGE
BV:58
LAT Cutoff Mode
R
n/a
n/a
n/a
latcmode_1
LATCMODE
