Features
Control Panel Function Keys
The following illustrations and tables display and describe the
function keys on the control panel. Refer to the following
sections for more information on the keys.
The following figure shows the keys of the upper section;
vd.
Of 07
JC
1
m
|03 1,09
11« II"'
f04 l|.o 11«
1 p
!□ L......... 1
f05 J[" IP 11''
mm mm^ mi rii______J
|06 11«
11« 1 j VI
¿Hr --i
Error Resolution Halftone Direct
Send
Busy aSuper Fine
0^3 Efme
Job Status aStandard
Q
1 1 1 1 1_______ 1 1_______ 1
The following table briefly describes the keys on the control
panel upper section:
Table 1-1: Control Panel
Upper Section
Key Function
Job Status Displays the status of a communication
occurring as a background job.
Resolution Selects the scanning resolution.
Halftone Selects the scanning contrast. Improves
the scanned image of a picture or
photograph.
Direct Send Used to transmit a document without
scanning the document into a memory file.
18 one-touch
keys (01-18) Transmits to a number assigned to the one
touch key.
6 group keys (1-
VI) Transmits to a group of numbers assigned
to a group key.
1-5
