Features
Hardware Features
The following figure shows the hardware features of the machine.
Refer to the
Mauntenance Procedures
chapter for information on
the internal hardware of the machine.
Control
Panel
LCD
Scanner
cover
Document
release
Guides
button
Input
tray
Printer
cover
release
button
Telephone
connection
AC
power
connection
Power
switch
Paper
cassette
1-2
